Proprietary TranSwitch Corporation Information for use Solely by its Customers
L3M
TXC-03452B
DATA SHEET
ORDERING INFORMATION
Part Number:
TXC-03452BIPQ
144-Lead Plastic Quad Flat Package
(not recommended for new designs)
TXC-03452CIPQ
144-Lead Plastic Quad Flat Package
TXC-03452CIOG
208-Lead Small Outline Plastic
Ball Grid Array Package
RELATED PRODUCTS
TXC-02030, DART VLSI Device (Advanced E3/DS3 Receiver/Transmitter). DART performs the
transmit and receive line interface functions required for transmission of E3 (34.368 Mbit/s) and DS3
(44.736 Mbit/s) signals across a coaxial interface.
TXC-02302B, SYN155C VLSI Device (155-Mbit/s Synchronizer, Clock and Data Output). Transmits
and receives at STS-3/STM-1 rates. Provides the complete STS-3/STM-1 frame synchronization
function. Connects directly to optical fiber interface components.
TXC-03001/TXC-03001B, SOT-1 VLSI Device (SONET STS-1 Overhead Terminator). This device
performs section, line and path overhead processing for STS-1 SONET signals. Has programmable
STS-1 or STS-N modes.
TXC-03003/TXC-03003B, SOT-3 VLSI Device (STM-1/STS-3/STS-3c Overhead Terminator). This
device performs section, line and path overhead processing for STM-1/STS-3/STS-3c signals.
Compliant with ANSI and ITU-TSS standards.
TXC-03303, M13E VLSI Device. Extended feature version of the TXC-03301 (M13).
TXC-03305, M13X VLSI Device (DS3/DS1 Mux/Demux). This single-chip device provides the
functions needed to multiplex and demultiplex 28 independent DS1 signals to and from a DS3 signal
with either an M13 or C-bit frame format. It includes some enhanced features relative to the M13E
device.
TXC-06103, PHAST-3N VLSI Device (SONET/SDH STM-1, STS-3 or STS-3c Overhead Terminator)
This PHAST-3N VLSI device provides a COMBUS interface for downstream devices and operates from
a power supply of 3.3 volts.
TXC-06125, XBERT VLSI Device (Bit Error Rate Generator Receiver). Programmable multi-rate test
pattern generator and receiver in a single chip with serial, nibble, or byte interface capability.
TXC-03452B-MB
Ed. 6, April 2001
- 88 of 96 -
