L3M
TXC-03452B
DATA SHEET
LIST OF DATA SHEET CHANGES
This change list identifies those areas within this updated L3M TXC-03452B Data Sheet that have significant
differences relative to the previous and now superseded Data Sheet:
Updated L3M TXC-03452B Data Sheet:
Previous L3M TXC-03452B Data Sheet:
Edition 6, April 2001
Edition 5A, February 2000
The page numbers indicated below of this updated data sheet include changes relative to the previous data
sheet.
Page Number of
Updated Data Sheet
Summary of the Change
Changed edition number and date.
All
2 -3
12
Updated the Table of Contents and List of Figures.
Changed the PBGA Lead Diagram labels for leads K15 and K16 to Symbols
TAIPF, TAIPD respectively.
22
23
In the Receive Desynchronizer table changed the lead Type for symbol CTRL.
In the Boundary Scan Testing Table, changed text of the Name/Function col-
umn for symbol TRS.
24
Added Note 5 below the Absolute Maximum Ratings and Environmental Limi-
tations table. In the Power Requirements Table changed the values in the Max
column for IDD and PDD
.
28
48
Added Note 2 for the RCLK duty cycle, below the table of Figure 8.
In the table below Figure 29, changed Boundary Scan Timing Min values for
Symbols tH(1), tSU(2), and tH(2). Changed the value in the Max column for
Symbol tD.
54
Changed title of Figure 34, added clock input for Rx PRBS Generator, and
added the note.
65
88
91
Added “Unequipped payload” to description of Symbol TPA1S00 (C2, Bit 3).
In the Related Products Section removed the fifth and last paragraphs.
Updated List of Data Sheet Changes.
TXC-03452B-MB
Ed. 6, April 2001
- 91 of 96 -
