C L A S S
30 AMP PC or FLANGE MOUNT 2 POLE RELAY
92
SPECIFICATIONS CLASS 92
TEMPERATURE
COIL
Pull-in Voltage:
Operating:
AC:-40˚C to +65˚C, DC:-40˚C to +85˚C
AC: 80% of Nominal Voltage or Less
DC: 75% of Nominal Voltage or Less
10% of Nominal voltage or More
120% Max.
14 Operations per minute
AC Coil: 4.0VA, DC Coil: 1.7W
Continuous
VIBRATION RESISTANCE
Dropout voltage:
Max. coil voltage:
Max. Operating Frequency:
Nominal Power:
Duty:
Functional:
0.065 (1.65 mm) double amplitude-10 thru 55 Hz
SHOCK RESISTANCE
Functional:
10 g's for 11 mS, 1/2 sign wave pulse with no
contact opening > 100µs
100 g for 11 ms 1/2 sine wave pulse
Class "F" (155˚C)
±10% Measured @ 25˚C
Insulation System:
Coil Resistance
Mechanical:
LIFE
CONTACT
Electrical (Rated Load) 100,000 Operations
Mechanical (No Load): 5 million Operations Typical
DPDT Standard
Silver Cadmium Oxide
Contact Configuration:
Contact Material:
SEE CONTACT LOAD RATINGS CHART
100 Milliohms @ Initial rated
current (switched)
N.O. 500 mA @ 12 VAC/VDC
N.C. 100mA @ 6 VAC/VDC
Contact Load Ratings:
Contact Resistance:
MISCELLANEOUS
Operating Position:
Enclosure:
Flammability:
Weight:
Any
Epoxy sealed immersion cleanable tape sealed plastic cover.
94V-O Flammability rating.
86 Grams, 3 oz approx.
Minimum Load:
TIMING
DC:15 mS typ. 25ms w/ bounce
DC:10mS typ. 25 ms w/ bounce
Operate Time:
Release Time:
DIELECTRIC STRENGTH
Between Open Contacts:
Contacts to coil:
1500 V rms
4000V rms
103 meg Ω min. @ 500 VDC, 25˚C 50% RH
Insulation Resistance
CONTACT RATINGS
Meets UL 873 and UL 508 spacing - (8mm) thru air, (9.5 mm) over surface.
AC Measured @ 50/60Hz
DPDT
DPST-N.O. & DPDT
N.O. CONTACTS
RATING
N.C. CONTACTS
Resistive
Load
30A @ 120/277 VAC
20A @ 28 VDC
3A @ 277VAC
3A @ 28VDC
1 HP @ 120VAC
2.5 HP @ 240VAC
Hp
Tungsten
LRA/FLA*
TV-10, 120VAC
96/22 @ 240VAC, AC Coil
110/25.3 @ 240VAC, DC Coil
Pilot Duty
3A @ 240 VAC
Note: Vent tape must be removed to achieve listed ratings
*
FLA = Full load Amps, LRA = Locked rotor Amps.
.
CROSS REFERENCE TO OMRON
Coil measured @ 25˚ C
PART NUMBERS
The relay listed below are crossed
to Magnecraft DPST-NO, 30 Amp,
Flange mount, Figure "B" only.
See Note below for Variations
between relays.
DPST-NO
30AMP
P.C. MT.
DPDT
30AMP
DPST-NO
30AMP-
DPDT
30AMP
NOMINAL
INPUT
NOMINAL
RESIS-
TANCE
(Ohms)
NOMINAL
POWER
P.C. MT.
FIGURE "A"
FLANGE MT. FLANGE MT.
FIGURE "B" FIGURE "B"
VOLTAGE
FIGURE "A"
OMRON PART NUMBERS
AC OPERATED COIL
24 VAC
120 VAC
240 VAC
-
-
-
4 VA
4 VA
4 VA
G7L-2A-TUBJ-CB-AC24
G7L-2A-TUBJ-CB-AC120
G7L-2A-TUBJ-CB-AC240
W92S11A22-24
W92S11A22-120
W92S11A22-240
W92S7A22-24
W92S7A22-120
W92S7A22-240
DC OPERATED COIL
W92S7D12-12 W92S11D12-12
W92S7D12-24 W92S11D12-24
W92S7D12-48 W92S11D12-48
W92S7D12-110 W92S11D12-110
12 VDC
24 VDC
48 VDC
110 VDC
1.7 W
1.7 W
1.7 W
1.7 W
G7L-2A-TUBJ-CB-DC12
G7L-2A-TUBJ-CB-DC24
86
350
1,390
7,255
W92S11D22-12
W92S11D22-24
W92S7D22-12
W92S7D22-24
G7L-2A-TUBJ-CB-DC110
W92S11D22-110
W92S7D22-110
G7L REPLACES G5D22423T
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
Note:
The Class W92 Meets Fit and Function when replacing the Omron G7L relay. The case size ( width & lenght ) and mounting
centers on flange are Dimensionally identical except the class 92 is lower in height. The W92 has a higher contact switching
rating then the G7L and requires less coil power for operation. The 1/4" (.250) Q.C. terminals on top of the case of the Class
92 are not located in the same positions as the G7L, but wire hookup will work with existing wiring using Q.C. connectors..
PAGE 52
