C9L A2S S
30 AMP PC or FLANGE MOUNT 2 POLE RELAY
Recognized Component mark for
Canada and the United States.
CLASS 92 RELAY
C
US
30 AMP SWITCHING.
CLASS "F" INSULATION.
PC or FLANGE MOUNTED.
EPOXY SEALED WITH
* REMOVABLE TAPE SEAL
OVER VENT HOLE
UL Recognized
File No. E43641
PC BOARD DRILL PATTERN
BOTTOM VIEWS
.630 ± .005
(16.00)
.162
(4.12)
.203 TYP
(5.16)
(REMOVED AFTER
CLEANING).
.309 ± .005
(7.85 ± .13)
.585 ± .005
(14.8 ± .13)
HOLE "B"
HOLE "A"
OUTLINE DIMENSIONS
Dimensions are in "inches" & (Millimeters)
.185 TYP
(4.70)
1.33 Max.
(33.78)
1.618 TYP
(41.10 ± .51)
1.00 ± .010
(25.40)
.309 ± .005
(7.85 ± .13)
HOLE "A" = .072 x .050 typ.
2.06 Max.
(52.32)
(1.83)
HOLE "B" = .052 x .050 typ.
(1.32)
FIGURE
"A"
P.C.
.586 ± .005
(14.8 ± .13)
MOUNT
.047 TYP.
Note: An alternate P.C. Board
layout Utilizes .076 ±.003 diameter
holes on the layout above. Use of
retangular holes is recommended
for improved solderability.
(1.19)
.250 TYP
(6.35)
1.618 TYP
(41.10 ± .51)
.156
(3.96)
.032 TYP
(0.81)
*Tape over vent hole is only supplied
on the P.C. terminal versions of this
relay.
.630 ± .005
(16.00)
1.10 Max.
(27.94)
1.00 ± .010
(25.40)
1.04 Max.
(26.42)
WIRING DIAGRAM
TOP VIEW
2
4
3
6
8
7
.309 ± .005
(7.85 ± .13)
2.06 Max.
(52.32)
0
1
FIGURE
"B"
DPDT
2.35 ±.005
(59.7 ±.13)
.585 ± .005
(14.8 ± .13)
FLANGE
MOUNT
2.70 Max.
(68.58)
2
4
6
8
.250 TYP
(6.35)
1.618 TYP
(41.10 ± .51)
0
1
DPST-NO
Only necessary terminals
are present on single
throw styles.
1.485 Max.
(37.72)
.090 Rad
1.36 Max.
(2.29) For
(34.54)
#8 screws
PAGE 51
