C L A S S
MINIATURE P.C. BOARD RELAY MOUNTABLE ON 0.100 GRID
60
SPECIFICATIONS CLASS 60
COIL
80% of Nominal Voltage or less
10% of nominal voltage or more
120% of nominal voltage, duty cycle 100%
327mW max. min. sensitivity: 200 mW
0.75 Watt
Pull-in Voltage:
Dropout Voltage:
Max. allowed voltage:
Nominal power:
Max. coil dissipation:
Coil Resistance
±10% Measured @ 25˚C
CONTACTS
Gold Clad Silver Palladium.
Contact Material:
Initial 50 Milliohms @ 6VDC, 10mA
100 Milliohms max., After life: 200 mΩ
Low Level: 50uA- 50mV,
Contact Resistance:
Contact Rating:
SPDT: 2A-24VDC, 2A-120VAC,
DPDT: 2A-24VDC, 0.6A-100VAC,
TIMING
4.0 mS Max. @ Nominal Voltage.
10.0 mS Max. @ Nominal Voltage.
2.5 mS operate, 5.0 mS release
Operate Time:
Release Time:
Contact bounce:
DIELECTRIC STRENGTH
500 VAC for 1 Minute, 1 Milliamp max.
leakage, or 600VAC for 1 Second,
1 Milliamp leakage.
Meets FCC 68.302 ( 1500V Surge )
and 68.304 ( 1000V Dielectric ).
500 VDC Exceeds 1000 Megohms.
All Mutually Insulated Points:
Surge Test:
Insulation Resistance:
TEMPERATURE
-35˚C to +70˚C
Operating:
VIBRATION RESISTANCE
15g's, 10 to 2000Hz, (No contact opening
greater than 10µS)
Functional:
SHOCK RESISTANCE
Functional:
50g's, 6mS Max.
Contact Chatter Destructive 50g's.
Mechanical:
LIFE
100,000 Operations Rated Load.
100 Million Operations
Electrical (Rated Load):
Mechanical (No Load):
MISCELLANEOUS
Terminals are solder Coated to provide
excellent solderability.
Terminal Finish:
Max. exposure to soldering temperature is
5 seconds @ 250˚C.
Any
Plastic.
Operating Position:
Enclosure:
Weight:
SPDT-5.5 g's, DPDT- 9 g's approx.
COIL Measured @ 25˚C
CROSS REFERENCE
TO
POTTER & BRUMFIELD
Pull-in
Resis-
tance
Contact
Configu-
ration
Nominal
Input
PART
NUMBERS
Power
(mW)
(Ohms)
Voltage
FIGURE "A"
W60HE1S-5DC SPDT
W60HE1S-12DC SPDT
W60HE1S-24DC SPDT
W60HE1S-48DC SPDT
FIGURE "B"
5VDC
12VDC
75
440
24VDC 1550
48VDC 5250
200
200
200
200
R50E2Y1-5V
R50E2Y1-12V
R50E2Y1-24V
R50E2Y1-48V
W60HE2S-5DC DPDT 5VDC
W60HE2S-12DC DPDT 12VDC
75
440
200
200
200
200
R50E2Y2-5V
R50E2Y2-12V
R50E2Y2-24V
R50E2Y2-48V
W60HE2S-24DC DPDT 24VDC 1550
W60HE2S-48DC DPDT 48VDC 5250
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
PAGE 56
