C L A S S
DOUBLE MAKE OR BREAK POWER RELAYS
199
CLASS 199 SPST-NC-DB
UL Listed
File No. E43641
COMPLIES WITH
OR SPST-NO-DM
RATED 30 AMPS @ 2 HP
CLASS "B" COIL
INSULATION SYSTEM
REQUIREMENTS OF
IEC STANDARDS
*
*
947-4-1 AND 947-5-1
LOW VOLTAGE DIRECTIVE
IEC = INTERNATIONAL
ELECTROTECHNICAL COMMISSION
OUTLINE DIMENSIONS
Dimensions shown in Inch & (Millimeters)
2.25 Max.
(57.15)
SPST-NC-DB
UP
.375
(9.5)
VERTICAL MOUNTING
RECOMMENDED WITH
CONTACTS UP
1.62
41.14
2.43 Max.
(61.7)
1.87
(47.5)
2.50
(63.5)
0.10
(2.54)
0.187 Dia.
(2 Places)
SPECIFICATIONS CLASS 199
COIL
Pull-in Voltage:
80% DC Coils, 85% AC coils of
nominal voltage or Less. @ 25˚C
10% of Nominal Voltage or More @ 25˚C
± 10% @ 25˚C
Dropout Voltage:
Coil Resistance:
DC Coils-4 Watts Max. Continuous.
Max. Coil Dissipation:
CONTACTS
SPST-NC (Double Break
SPST-NO (Double Make
Contact Combinations:
30 Amps up to 300 VAC, 50/60Hz
12 Amps@ 480, 10 Amps @ 600VAC,50/60
0.75pFInductive Load. 2 HP Motor Load
@ 120 thru 600 VAC, 50/60 Hz. 30Amps
@ 28VDCResistive load.
Contact Rating SPST-NO-DM:
SPST-NO-DM
NEMA A600 Pilot Duty 50/60Hz
Silver Cadmium Oxide, Gold Flashed.
5/16" Diameter Standard.
:
Contact Material:
* RELEVANT IEC CONTACT UTILIZATION CATEGORIES
AC-1, AC-3, DC-1, AC-15
TIMING
SEE SECTION 11, FOR RELEVANT UTILIZATION CATEGORIES
40 Milliseconds Max. @ Nominal V
30 Milliseconds Max. @ Nominal V
Operate time
Release Time:
DIELECTRIC STRENGTH
Between Open Contacts:
Mutually Insulated
Measured @ 25˚C
COIL
CROSS
1500 V rms
2200 V rms
PART
NUMBERS
REFERENCE
POTTER &
BRUMFIELD
NOMINAL
RESIS-
NOMINAL
POWER
NOMINAL
INPUT
VOLTAGE
Conductive elements:
TANCE
TEMPERATURE
Operating Range:
Non-Operating Storage
range:
(OHMS)
(AC) -30˚C to +50˚C, (DC) -30˚C +60˚C
-30˚C to +100˚C
DC OPERATED (SPST-NC-DB WITH 30 AMP SCREW TERMINALS)
70
PRD4DG0-12
AC OPERATED (SPST-NO-DM WITH 30 AMP SCREW TERMINALS)
W199DYX-2
12 VDC
2.0 W
LIFE
100,000 Operations
5,000,000 Operations
Electrical (Rated Load):
Mechanical (No Load):
-
PRD3AG0-120
PRD3AG0-240
W199ADX-4
120 VAC
10 VA
MISCELLANEOUS
Coil Terminals:
W199ADX-5 240 VAC, 60 Hz
6-32 Binder Head Screws
8-32 Binder Head Screws
Molded Phenolic, UL recognized
(QMz2)
-
10 VA
220 VAC, 50 Hz
Contacts Terminals:
Base Material:
DC OPERATED (SPST-NO-DM WITH 30 AMP SCREW TERMINALS)
8 oz. - 227 Grams approx.
Weight:
70
290
PRD3DG0-12
PRD3DG0-24
W199DX-2
W199DX-3
12 VDC
24 VDC
2.0 W
2.0 W
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
AUXILIARY CONTACTS AND OTHER COIL VOLTAGES ARE
AVAILABLE ON SPECIAL ORDER. CONTACT FACTORY FOR
SPECIAL REQUIREMENTS.
WEBSITE: www.magnecraft.com EMAIL:info@magnecraft.com FAX ON DEMAND 1-800/891-2957, DOCUMENT 100
PAGE 144
