C L A S S
OPEN STYLE 30 AMP POWER RELAY
199
CLASS 199 DPDT
30 AMP - 1-1/2 Hp
CLASS "B" COIL
INSULATION SYSTEM
UL Listed
File No. E43641
COMPLIES WITH
REQUIREMENTS OF
IEC STANDARDS
*
947-4-1 AND 947-5-1
LOW VOLTAGE DIRECTIVE
IEC = INTERNATIONAL
ELECTROTECHNICAL COMMISSION
*
OUTLINE DIMENSIONS
Dimensions shown in Inch & (Millimeters)
2.31 Max.
(58.67)
UP
VERTICAL MOUNTING
1.87
1.62
(41.1)
RECOMMENDED WITH
CONTACTS UP
(47.5)
2.50
(63.5)
3.12
(79.2)
.375
(9.5)
0.187 Dia.
(2 Places)
SPECIFICATIONS CLASS 199
* RELEVANT IEC CONTACT UTILIZATION CATEGORIES
COIL
AC-1, AC-3, DC-1, AC-15
Pull-in Voltage:
80% DC Coils, 85% AC coils of
nominal voltage or Less @ 25˚C
10% of Nominal Voltage or More @ 25˚C
± 10% @ 25˚C
SEE SECTION 11, FOR RELEVANT UTILIZATION CATEGORIES
Dropout Voltage:
Coil Resistance:
Max. Coil Dissipation:
DC Coils-4 Watts Max. Continuous.
CONTACTS
Contact Combinations:
Measured @ 25˚C
COIL
DPDT
CROSS
PART
NUMBERS
Contact Rating each Pole: 30 Amps up to 300VAC, 50/60Hz
5 Amps @ 480/600 VAC 50/60Hz, 0.75pF
Inductive Load. 1-1/2 HP Motor Load (each
Pole) @ 120 thru 600 VAC, 50/60 Hz. 2 HP
Motor Load @ 200 thru 600 VAC, 50/60 Hz
only when using two poles to switch both
sides of Load.
NOMINAL
INPUT
VOLTAGE
NOMINAL
RESIS-
NOMINAL
POWER
REFERENCE
POTTER &
BRUMFIELD
TANCE
(OHMS)
AC OPERATED (DPDT)
30 Amps @ 28 VDC Resistive Each Pole.
NEMA A600 Pilot Duty 50/60HZ
-
-
W199AX-13
W199AX-14
W199AX-15
24 VAC
120 VAC
10 VA
10 VA
PRD11AGO-24
PRD11AGO-120
PRD11AGO-240
240 VAC, 60 Hz
220 VAC, 50 Hz
Contact Material:
Silver Cadmium Oxide, Gold Flashed.
5/16" Diameter Standard.
-
10 VA
TIMING
DC OPERATED (DPDT)
Operate time
40 Milliseconds Max. @ Nominal V
30 Milliseconds Max. @ Nominal V
Release Time:
18
70
290
6000
W199X-11
W199X-12
W199X-13
W199X-14
6 VDC
2.0 W
2.0 W
2.0 W
2.0 W
PRD11DGO-6
PRD11DGO-12
PRD11DGO-24
PRD11DGO-110
12 VDC
24 VDC
110 VDC
DIELECTRIC STRENGTH
Between Open Contacts: 1500 V rms
Mutually Insulated
Conductive elements:
2200 V rms
RECTIFIED, AC OPERATED (DPDT)
TEMPERATURE
Operating Range:
Non-Operating Storage
range:
(AC) -30˚C to +50˚C, (DC) -30˚C +60˚C
-30˚C to +100˚C
-
W199AXD-38 ✝ 208, 240, 277 VAC
See Note ✝✝
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
Built in Coil Diodes provide a wide range of Nominal Coil input
voltages. This relay is suitable to Operate within a range of
208 Vac thru 277 Vac.
LIFE
✝
Electrical (Rated Load):
Mechanical (No Load):
100,000 Operations
5,000,000 Operations
208 Vac = 2.3 VA, 240 Vac = 3.0 VA, 277 Vac = 4.0 VA.
✝✝
MISCELLANEOUS
Coil Terminals: l
Contact Terminals:
Base Material:
6-32 Binder Head Screws
8-32 Binder Head Screws
Molded Phenolic, UL Recognized
(QMFZ2)
AUXILIARY CONTACTS AND OTHER COIL VOLTAGES ARE
AVAILABLE ON SPECIAL ORDER. CONTACT FACTORY FOR
SPECIAL REQUIREMENTS.
Weight:
11 oz. - 311 Grams approx. (DPDT)
PAGE 141
WEBSITE: www.magnecraft.com EMAIL:info@magnecraft.com FAX ON DEMAND 1-800/891-2957, DOCUMENT 100
