C L A S S
OPEN STYLE POWER RELAY
199
CLASS 199 DPST-NO
1-1/2 HP PER POLE
UL Listed
File No. E43641
COMPLIES WITH
2 Hp - 2 POLE SWITCHING
CLASS "B" COIL
REQUIREMENTS OF
IEC STANDARDS
*
*
947-4-1 AND 947-5-1
LOW VOLTAGE DIRECTIVE
INSULATION SYSTEM
IEC = INTERNATIONAL
ELECTROTECHNICAL COMMISSION
OUTLINE DIMENSIONS
Dimensions shown in Inch & (Millimeters)
2.25 Max.
(57.15)
UP
.375
(9.5)
VERTICAL MOUNTING
RECOMMENDED WITH
CONTACTS UP
1.62
1.87
(47.5
41.14
2.50
(63.5)
2.43 Max.
(61.7)
0.187 Dia.
(2 Places)
SPECIFICATIONS CLASS 199
COIL
Pull-in Voltage:
80% DC Coils, 85% AC coils of
nominal voltage or Less @ 25˚C
10% of Nominal Voltage or More @ 25˚C
± 10% Measured @ 25˚C
Dropout Voltage:
Coil Resistance:
Max. Coil Dissipation:
DC Coils-4 Watts Max. Continuous.
CONTACTS
Contact Combinations:
Contact Rating each Pole:
DPST-NO
Each pole rated 30 Amps up to 300 VAC,
50/60Hz, 5 Amps@ 480/600VAC ,0.75pF
* RELEVANT IEC CONTACT UTILIZATION CATEGORIES
Inductive load. 1-1/2 HP Motor Load (each
Pole) @ 120 thru 600 VAC, 50/60 Hz. 2 HP
Motor Load @ 200 thru 600 VAC, 50/60
Hz only when using two pole toswitchboth
sides of Load 30Amps @ 28VDCResistive
load each Pole.
AC-1, AC-3, DC-1, AC-15
SEE SECTION 11, FOR RELEVANT UTILIZATION CATEGORIES
NEMA A600 Pilot Duty 50/60Hz
Measured @ 25˚C
COIL
CROSS
Contact Material:
Silver Cadmium Oxide, Gold Flashed.
5/16" Diameter Standard.
PART
NOMINAL
POWER
NOMINAL
RESIS-
TANCE
REFERENCE
POTTER &
BRUMFIELD
NOMINAL
INPUT
VOLTAGE
NUMBERS
TIMING
DPST-NO
(OHMS)
Operate time
Release Time:
40 Milliseconds Max. @ Nominal V
35 Milliseconds Max. @ Nominal V
AC OPERATED (DPST-NO)
-
-
PRD7AGO-24
PRD7AGO-120
PRD7AGO-240
W199AX-8
W199AX-9
W199AX-10 240 VAC, 60 Hz
24 VAC
120 VAC
10 VA
10 VA
DIELECTRIC STRENGTH
Between Open Contacts:
Mutually Insulated
1500 V rms
2200 V rms
-
220 VAC, 50 Hz
10 VA
Conductive elements:
DC OPERATED (DPST-NO)
TEMPERATURE
Operating Range:
Non-Operating Storage
range:
(AC) -30˚C to +50˚C, (DC) -30˚C +60˚C
-30˚C to +100˚C
70
290
PRD7DGO-12
PRD7DGO-24
W199X-7
W199X-8
12 VDC
24 VDC
2.0 W
2.0 W
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
LIFE
100,000 Operations
5,000,000 Operations
Electrical (Rated Load):
Mechanical (No Load):
AUXILIARY CONTACTS AND OTHER COIL VOLTAGES ARE
AVAILABLE ON SPECIAL ORDER. CONTACT FACTORY FOR
SPECIAL REQUIREMENTS.
MISCELLANEOUS
Coil Terminals:
6-32 Binder Head Screws
8-32 Binder Head Screws
Molded Phenolic, UL Recognized
(QMFZ2)
Contact Terminals:
Base Material:
9 oz. - 255 Grams approx... (DPST-NO)
Weight:
PAGE 142
WEBSITE: www.magnecraft.com EMAIL:info@magnecraft.com FAX ON DEMAND 1-800/891-2957, DOCUMENT 100
