Table 6.1
Symbol
L64777 Absolute Maximum Ratings
Parameter
Limits
Unit
VDD
VIN
DC Supply
−0.3 to 3.9
−1.0 to VDD + 0.3
−1.0 to 6.5
10
V
LVTTL Input Voltage
5 V Compatible Inputs
DC Input Current
V
VIN
V
IIN
mA
°C
TSTG
Storage Temperature Range
(Plastic)
−40 to +150
TJ
Operating Junction Temperature
Range
0 to +125
°C
Table 6.2
Symbol
L64777 Recommended Operating Conditions
Parameter
Limits
Unit
VDD
TA
DC Supply
+ 3.14 to + 3.45
V
Ambient Temperature 0 to + 70
°C
When studying the values in Table 6.3, note that the L64777 follows
the LSI Logic G10-p process, which is characterized by a 0.35-micron
gate length.
Table 6.3
L64777 DC Characteristics
Symbol Parameter
Condition1
Min
Typ
Max
Units
VDD
VIL
Supply Voltage
3.14
Vss − 0.5
2.0
3.3
3.45
0.8
V
V
Input Voltage LOW
Input Voltage HIGH
Output Voltage HIGH
Output Voltage LOW
VIH
VOH
VOL
IOZ
VDD + 0.3
VDD
V
IOH = −4.0 mA
2.4
V
IOL = 4.0 mA
0.2
0.4
V
Current 3-State Leakage
w/Pulldown
VDD = Max, VOUT
VSS or VDD
=
−10
± 1
10
µA
6-2
Specifications
