Chapter 6
Specifications
This chapter provides information about the electrical ratings, pins, and
packaging for the L64777. It consists of the following sections:
•
•
•
Section 6.1, “AC/DC Specifications,” page 6-1
Section 6.2, “Pin Descriptions and Lists,” page 6-5
Section 6.3, “Package Pinout,” page 6-10
6.1 AC/DC Specifications
This section lists the electrical requirements, provides the AC timing
characteristics, shows the AC timing diagrams, and lists the AC timing
values for the L64777 decoder.
6.1.1 Electrical Ratings
The tables in this section specify the electrical requirements for the
L64777 decoder. Table 6.1 provides the L64777 absolute maximum
electrical and temperature ratings. Table 6.2 provides the L64777
recommended operating conditions. Table 6.3 lists the DC characteristics
for the L64777.
