Signal Description
Table 2-4. Primary PCI Interface Signals (Sheet 2 of 2)
Name
Type
Description
System Error: The 82443BX asserts this signal to indicate an error condition. The
SERR# assertion by the 82443BX is enabled globally via SERRE bit of the PCICMD
register. SERR# is asserted under the following conditions:
In an ECC configuration, the 82443BX asserts SERR#, for single bit (correctable)
ECC errors or multiple bit (non-correctable) ECC errors if SERR# signaling is enabled
via the ERRCMD control register. Any ECC errors received during initialization should
be ignored.
•
•
•
•
•
The 82443BX asserts SERR# for one clock when it detects a target abort during
82443BX initiated PCI cycle.
The 82443BX can also assert SERR# when a PCI parity error occurs during the
address or data phase.
I/O
SERR#
The 82443BX can assert SERR# when it detects a PCI address or data parity
error on AGP.
PCI
The 82443BX can assert SERR# upon detection of access to an invalid entry in
the Graphics Aperture Translation Table.
The 82443BX can assert SERR# upon detecting an invalid AGP master access
outside of AGP aperture and outside of main DRAM range (i.e. in the 640k - 1M
range or above TOM).
•
•
The 82443BX can assert SERR# upon detecting an invalid AGP master access
outside of AGP aperture.
The 82443BX asserts SERR# for one clock when it detects a target abort during
82443BX initiated AGP cycle.
Stop: STOP# is an input when the 82443BX acts as a PCI initiator and an output
when the 82443BX acts as a PCI target. STOP# is used for disconnect, retry, and
abort sequences on the PCI Bus.
I/O
STOP#
PCI
NOTE:
1. All PCI interface signals conform to the PCI Rev 2.1 specification.
2.4
Primary PCI Sideband Interface
Table 2-5.
Signals
Primary PCI Sideband Interface
Name
Type
Description
PCI Hold: This signal comes from the PIIX4E. It is the PIIX4E request for PCI bus
ownership. The 82443BX will flush and disable the CPU-to-PCI write buffers before
granting the PIIX4E the PCI bus via PHLDA#. This prevents bus deadlock between
PCI and ISA.
I
PHOLD#
PCI
O
PCI
PCI Hold Acknowledge: This signal is driven by the 82443BX to grant PCI bus
ownership to the PIIX4E after CPU-PCI post buffers have been flushed and disabled.
PHLDA#
WSC#
Write Snoop Complete. This signal is asserted active to indicate that all that the
snoop activity on the CPU bus on the behalf of the last PCI-DRAM write transaction is
complete and that is safe to send the APIC interrupt message.
O
CMOS
I
PCI Bus Request: PREQ[4:0]# are the PCI bus request signals used as inputs by the
internal PCI arbiter.
PREQ[4:0]#
PGNT[4:0]#
PCI
O
PCI
PCI Grant: PGNT[4:0]# are the PCI bus grant output signals generated by the internal
PCI arbiter.
2-6
82443BX Host Bridge Datasheet
