NT5DS32M4AT
NT5DS16M8AT
128Mb Double Data Rate SDRAM
Write to Write: Max DQSS, Non-Consecutive (Burst Length = 4)
T1
T2
T3
T4
T5
CK
CK
Write
NOP
NOP
Write
NOP
Command
Address
BAa, COL b
BAa, COL n
t
(max)
DQSS
DQS
DQ
DI a-b
DI a-n
DM
DI a-b, etc. = data in for bank a, column b, etc.
3 subsequent elements of data in are applied in the programmed order following DI a-b.
3 subsequent elements of data in are applied in the programmed order following DI a-n.
A non-interrupted burst is shown.
Don’ t Care
Each Write command may be to any bank.
33
REV 1.0
May, 2001
©
NANYA TECHNOLOGY CORP. All rights reserved.
NANYA TECHNOLOGY CORP. reserves the right to change Products and Specifications without notice.
