ZENTRUM MIKROELEKTRONIK DRESDEN AG
“ASI for you” IC
Datasheet
1.4 Package Pin Assignment
Table 4: ASI4U Pin List
Package
Name
Direction Type
Description
pin number
1
ASIP
IN
Analog
AS-i Transmitter/Receiver input, to be connected to
ASI+ lead of AS-i cable, via reverse polarity protec-
tion diode
2
3
ASIN
0V
OUT
Analog
AS-i Transmitter/Receiver output, to be connected to
ASI- lead of AS-i cable
SUPPLY
IC Ground
Common ground for all IC ports except ASIP/ASIN,
To be connected to ASIN if no external coils are used
4
5
IRD
IN
Analog / CMOS (5V) Addressing Channel input
FID
IN
Pull-up
Periphery Fault input
Crystal oscillator
6
OSC2
OSC1
DO3
DO2
DO1
DO0
GND
P3
OUT
IN
Analog (5V)
7
Analog / CMOS (5V) Crystal oscillator / External clock input
8
OUT
OUT
OUT
OUT
Open Drain
Open Drain
Open Drain
Open Drain
SUPPLY
Data port output D3
9
Data port output D2
10
11
12
13
14
Data port output D1
Data port output D0
Digital I/O ground, to be connected with 0V
I/O
I/O
Pull-up/Open Drain Parameter port P3
Pull-up/Open Drain Parameter port P2 /
P2
Receive Strobe output in Master Mode
Pull-up/Open Drain Parameter port P1 /
Power Fail output in Master Mode
Pull-up/Open Drain Parameter port P0 /
Data Clock output in Master Mode
Data port input D0
15
16
P1
P0
I/O
I/O
17
18
19
20
21
DI0
DI1
DI2
DI3
PST
IN
IN
IN
IN
I/O
Pull-up
Pull-up
Pull-up
Pull-up
Data port input D1
Data port input D2
Data port input D3
Pull-up/Open Drain Parameter Strobe output
(input function used for IC test purposes only)
Pull-up/Open Drain Data Strobe output / Reset input
22
DSR
I/O
