YMF724F
ELECTRICAL CHARACTERISTICS
1. Absolute Maximum Ratings
Item
Symbol
Min.
Max.
Unit
Power Supply Voltage 1 (PVDD, VDD5)
Power Supply Voltage 2 (VDD3, LVDD)
Input Voltage 1 (PVDD, VDD5)
Input Voltage 2 (VDD3, LVDD)
Operating Ambient Temperature
Storage Temperature
VDD5
VDD3
VIN5
VIN3
TOP
-0.5
-0.3
-0.5
-0.3
0
7.0
4.6
V
V
VDD5+0.5
VDD3+0.3
70
V
V
°C
°C
TSTG
-50
125
Note : PVSS=LVSS=VSS=0[V]
2. Recommended Operating Conditions
Item
Symbol
Min.
Typ.
Max.
Unit
Power Supply Voltage 1 (PVDD, VDD5)
Power Supply Voltage 2 (VDD3, LVDD)
Operating Ambient Temperature
VDD5
VDD3
TOP
4.75
3.00
0
5.00
3.30
25
5.25
3.60
70
V
V
°C
Note : PVSS=LVSS=VSS=0[V]
