SYSCLK CONTROL
MCLK may be inverted by setting register bit MCLK_INV. Note that it is not recommended to change
the control bit MCLK_INV while the WM8959 is processing data as this may lead to clock glitches
and signal pop and clicks.
The SYSCLK_SRC bit is used to select the source for SYSCLK. The source may be either MCLK or
the PLL output. The selected source is divided by the SYSCLK pre-divider MCLK_DIV to generate
SYSCLK. The selected source may also be adjusted by the MCLK_DIV divider. These register fields
are described in Table 56. See “PLL” for more details of the Phase Locked Loop clock generator.
The WM8959 supports glitch-free SYSCLK source selection. When both clock sources are running
and SYSCLK_SRC is modified to select one of these clocks, a glitch-free clock transition will take
place. The de-glitching circuit will ensure that the minimum pulse width will be no less than the pulse
width of the faster of the two clock sources.
When the initial clock source is to be disabled before changing to the new clock source, the
CLK_FORCE bit must also be used to force the clock source transition to take place. In this case,
glitch-free operation cannot be guaranteed.
REGISTER
ADDRESS
BIT
14
LABEL
DEFAULT
DESCRIPTION
SYSCLK Source Select
R7 (07h)
SYSCLK_SRC
0b
0 = MCLK
1 = PLL output
13
CLK_FORCE
0b
Forces Clock Source Selection
0 = Existing SYSCLK source (MCLK or
PLL output) must be active when
changing to a new clock source.
1 = Allows existing MCLK source to be
disabled before changing to a new clock
source.
12:11
MCLK_DIV
[1:0]
00b
SYSCLK Pre-divider. Clock source
(MCLK or PLL output) will be divided by
this value to generate SYSCLK.
00 = Divide SYSCLK by 1
01 = Reserved
10 = Divide SYSCLK by 2
11 = Reserved
10
MCLK_INV
0b
MCLK Invert
0 = Master clock not inverted
1 = Master clock inverted
Table 56 MCLK and SYSCLK Control
