WM8959
Pre-Production
DESCRIPTION
DACLRC Rate
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
10:0
DACLRC_RATE
[10:0]
040h
DACLRC clock output = BCLK /
DACLRC_RATE
Integer (LSB = 1)
Valid from 8..2047
Table 53 Digital Audio Interface Clock Output Control
COMPANDING
The WM8959 supports A-law and µ-law companding as shown in Table 54.
REGISTER BIT
ADDRESS
LABEL
DEFAULT
DESCRIPTION
R5 (05h)
4
DAC_COMP
0b
DAC Companding Enable
0 = disabled
1 = enabled
3
DAC_COMPMODE
0b
DAC Companding Type
0 = µ-law
1 = A-law
Table 54 Companding Control
Companding involves using a piecewise linear approximation of the following equations (as set out
by ITU-T G.711 standard) for data compression:
µ-law (where µ=255 for the U.S. and Japan):
F(x) = ln( 1 + µ|x|) / ln( 1 + µ)
A-law (where A=87.6 for Europe):
F(x) = A|x| / ( 1 + lnA)
-1 ≤ x ≤ 1
} for x ≤ 1/A
} for 1/A ≤ x ≤ 1
F(x) = ( 1 + lnA|x|) / (1 + lnA)
The companded data is also inverted as recommended by the G.711 standard (all 8 bits are inverted
for µ-law, all even data bits are inverted for A-law). The data will be transmitted as the first 8 MSBs
of data.
Companding converts 13 bits (µ-law) or 12 bits (A-law) to 8 bits using non-linear quantization. This
provides greater precision for low amplitude signals than for high amplitude signals, resulting in a
greater usable dynamic range than 8 bit linear quantization. The companded signal is an 8-bit word
comprising sign (1 bit), exponent (3 bits) and mantissa (4 bits).
8-bit mode is selected whenever DAC_COMP=1. The use of 8-bit data allows samples to be passed
using as few as 8 BCLK cycles per LRC frame. When using DSP mode B, 8-bit data words may be
transferred consecutively every 8 BCLK cycles.
8-bit mode (without Companding) may be enabled by setting DAC_COMPMODE=1 and
DAC_COMP=0.
BIT7
BIT[6:4]
BIT[3:0]
SIGN
EXPONENT
MANTISSA
Table 55 8-bit Companded Word Composition
PP, May 2008, Rev 3.1
102
