WM8774
Product Preview
DIGITAL AUDIO INTERFACE – SLAVE MODE
BCLK
ADCLRC
DVD
Controller
WM8774
CODEC
DACLRC
DOUT
DIN
Figure 4 Audio Interface – Slave Mode
tBCH
tBCL
BCLK
tBCY
DACLRC/
ADCLRC
tLRSU
tDS
tLRH
DIN
tDD
tDH
DOUT
Figure 5 Digital Audio Data Timing – Slave Mode
Test Conditions
AVDD = 5V, DVDD = 3.3V, AGND = 0V, DGND = 0V, TA = +25oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless otherwise
stated.
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Audio Data Input Timing Information
BCLK cycle time
tBCY
tBCH
tBCL
50
20
20
10
ns
ns
ns
ns
BCLK pulse width high
BCLK pulse width low
DACLRC/ADCLRC set-up
time to BCLK rising edge
tLRSU
DACLRC/ADCLRC hold
time from BCLK rising edge
tLRH
tDS
tDH
tDD
10
10
10
0
ns
ns
ns
ns
DIN set-up time to BCLK
rising edge
DIN hold time from BCLK
rising edge
DOUT propagation delay
from BCLK falling edge
10
Table 3 Digital Audio Data Timing – Slave Mode
Note:
1. ADCLRC and DACLRC should be synchronous with MCLK, although the WM8774 interface is tolerant of phase
variations or jitter on these signals.
PP Rev 1.0 June 2002
10
ꢀꢀ
