Production Data
WM8352
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
Right output mixer enable.
REFER TO
R89 (59h)
Right Mixer
Control
15
12
11
3
MIXOUTR_ENA
0
0 = disabled
1 = enabled
DACR_TO_MIXOUTR
DACL_TO_MIXOUTR
IN3R_TO_MIXOUTR
INR_TO_MIXOUTR
INL_TO_MIXOUTR
1
0
0
0
0
Right DAC output to right output mixer
0 = not selected
1 = selected
Left DAC output to right output mixer
0 = not selected
1 = selected
IN3R amplifier output to right output mixer:
0 = not selected
1 = selected
1
Right input PGA output to right output mixer
0 = not selected
1 = selected
0
Left input PGA output to right output mixer
0 = not selected
1 = selected
Register 59h Right Mixer Control
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
R92 (5Ch)
OUT3 Mixer
Control
15
OUT3_ENA
0
OUT3 enable
0 = disabled
1 = enabled
11
8
DACL_TO_OUT3
MIXINL_TO_OUT3
OUT4_TO_OUT3
0
0
0
0
Left DAC output to OUT3
0 = disabled
1 = enabled
Left input mixer to OUT3
0 = disabled
1 = enabled
3
OUT4 mixer to OUT3
0 = disabled
1 = enabled
0
MIXOUTL_TO_OUT3
Left output mixer to OUT3
0 = disabled
1 = enabled
Register 5Ch OUT3 Mixer Control
PD, February 2011, Rev 4.4
