14.4.3 CONFIGURING THE WM8352 IN DEVELOPMENT MODE
The WM8352 can be configured in Development mode by writing to control bits that determine its
startup behaviour. The locations of these register bits are shown in Table 64 below. A typical
configuration sequence would include writes to some or all of the registers listed. If none of the
highlighted bits in any given register needs to be changed from its default, then no write to that
register is recommended.
The configuration bits include:
.
.
Duration control bits for the /RST reset signal (RSTB_TO)
GPIO pull-up / pull-down settings and debounce times (GPn_PD, GPn_PU, GPn_DB and
GP_DBTIME)
.
Alternate function and input/output selection for GPIO pins (GPn_FN, GPn_DIR and
GPn_CFG)
.
.
Voltage settings for DC-DC converters and LDO regulators (DCn_VSEL and LDOn_VSEL)
Time slots for automatic start of all DC-DC converters, all LDO regulators and the Current
Limit Switch during startup (DCn_ENSLOT, LDOn_ENSLOT and LS_ENSLOT). Note that
supplies can be programmed to not start up automatically by setting the respective
_ENSLOT bits to 0000.
Typically, the final step in the sequence is a write to register R6, in order to:
.
.
.
Select the WM8352 device address on the primary control interface, using the DEV_ADDR
bits.
Allow the WM8352 to proceed to startup. This is achieved by setting the CONFIG_DONE
bit (R6 bit 12) to 1.
Switch the control interface back to the primary interface (if desired), so that a host
processor can communicate with the WM8352. This is achieved by setting
USE_DEV_PINS (R6 bit 15) to 0.
