W90N745CD/W90N745CDG
GPIO Port5 Data Output Register (GPIO_DATAOUT5)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
GPIO_DATAOUT5
0xFFF8_3058
R/W
GPIO port5 data output register
0x0000_0000
31
23
15
30
22
14
29
21
13
28
27
19
11
3
26
18
25
17
9
24
16
8
RESERVED
20
RESERVED
12
10
RESERVED
6
DATAOUT5[12:8]
2
7
5
4
1
0
DATAOUT5[7:0]
BITS
DESCRIPTION
[31:13]
RESERVED
-
PORT5 data output value
Writing data to this register will reflect the data value on the
corresponding port5 pin when it is configured as general purpose
output pin. And writing data to reserved bits is not effective.
[12:0]
DATAOUT5
GPIO Port5 Data Input Register (GPIO_DATAIN5)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
GPIO_DATAIN5
0xFFF8_305C
R/W
GPIO port5 data input register
0xXXXX_XXXX
31
23
15
30
22
14
29
21
13
28
27
19
11
3
26
18
25
24
16
8
RESERVED
20
17
9
RESERVED
12
10
RESERVED
6
DATAIN5[12:8]
2
7
5
4
1
0
DATAIN5[7:0]
