W90N745CD/W90N745CDG
BITS
DESCRIPTIONS
[31:5]
Reserved
-
Frame valid indicated bits
VALID_FRAME=1, any one of slot is valid
VALID_FRAME=0, no any slot is valid
The VALID_FRAME bits are read/write
[4]
VALID_FRAME
Slot valid indicated bits
SLOT_VALID[0]= 1/0, indicate Slot 1 valid/invalid
SLOT_VALID[1]= 1/0, indicate Slot 2 valid/invalid
SLOT_VALID[2]= 1/0, indicate Slot 3 valid/invalid
SLOT_VALID[3]= 1/0, indicate Slot 4 valid/invalid
The SLOT_VALID[3:0] bits are read/write
SLOT_VALID
[3:0]
[3:0]
The AC-link output slot 1 (ACTL_ACOS1)
REGISTER
ADDRESS
R/W
DESCRIPTION
AC-link out slot 1
RESET VALUE
0xFFF0_9034 R/W
0x0000_0080
ACTL_ACOS1
The ACTL_ACOS1 register store the slot 1 value to be shift out by AC-link.
31
23
15
30
22
14
6
29
21
13
5
28
Reserved
20
Reserved
12
Reserved
27
19
11
26
18
10
2
25
24
16
8
17
9
7
4
3
1
0
R_WB
R_INDEX[6:0]
