W83697HF/F
9.7.17 Winbond Vendor ID Register - Index 4Fh (No Auto Increase)
Register Location:
Power on Default Value
Attribute:
4Fh
<15:0> = 5CA3h
Read Only
16 bits
Size:
15
8
7
0
VIDH
VIDL
Bit 15-8: Vendor ID High Byte if CR4E.bit7=1.Default 5Ch.
Bit 7-0: Vendor ID Low Byte if CR4E.bit7=0. Default A3h.
9.7.18 Winbond Test Register -- Index 50h - 55h (Bank 0)
Bank 0
9.7.19 BEEP Control Register 1-- Index 56h (
)
Register Location:
Power on Default Value
Attribute:
56h
00h
Read/Write
8 bits
Size:
7
6
5
4
3
2
1
0
EN_VC_BP
Reserved
EN_V33_BP
EN_AVCC_BP
EN_T1_BP
EN_T2_BP
EN_FAN1_BP
EN_FAN2_BP
Bit 7: Enable BEEP Output from FAN 2 if the monitor va lue exceed the limit value. Write 1, enable
BEEP output, which is default value.
Bit 6: Enable BEEP Output from FAN 1 if the monitor value exceed the limit value. Write 1, enable
BEEP output, which is default value.
Publication Release Date: Feb. 2002
- 111 -
Revision 0.70
