Notes:
(1) These P-channel transistors have a high drain to gate charge, which may introduce destructive
current impulses into the HA/HB outputs by forcing them above the power supply level, especially
when the miller capacitance (QGD) of the low side MOSFET is lower and thus it switches more
quickly. As a thumb rule, the criteria is QGDHS / QGSHS * QGDHS / QGDLS > 2 (assuming slopes >100ns).
To ensure reliability, connect a 500mA or 1A Schottky diode to both HA and HB outputs against
VS to protect them. Types like MSS1P3, ZHCS1000, SS14 or BAR43 can be used.
(2) These N-channel transistors have a high drain to gate charge, which may introduce destructive
current impulses into the LA/LB outputs by forcing them below the ground level, especially when
the miller capacitance (QGD) of the high side MOSFET is lower and thus it switches more quickly.
As a thumb rule, the criteria is QGDLS / QGSLS * QGDLS / QGDHS > 2 (assuming slopes >100ns).
To ensure reliability, connect a 500mA or 1A Schottky diode to both LA and LB outputs against
GND to protect them against negative spikes. Types like MSS1P3, ZHCS1000, SS14 or BAR43 can be
used.
