VDROP is the minimum input voltage where the converter can still maintain output regulation (see 方程式92). The
converter’s input voltage would only drop down this low during a brownout or line-drop condition if this
converter was following a PFC pre-regulator.
æ
ç
è
ö
÷
ø
2´DCLAMP ´ VRDSON + a1´(VOUT + VRDSON
)
VDROP
=
= 276.2V
DCLAMP
(92)
CIN was calculated in 方程式93 based on one line cycle of holdup:
1
2´POUT
´
60Hz
CIN ³
» 364mF
2
V
2 - VDROP
(
)
IN
(93)
(94)
Calculate the high-frequency input capacitor RMS current (ICINRMS) using 方程式94.
P
2
OUT
I
=
I
−
= 1.8 A
× η
CINRMS
PRMS1
V
VIN min
To meet the input capacitance and RMS current requirements for this design, a 330-µF capacitor was chosen
from Panasonic part number EETHC2W331EA:
CIN = 330 µF
This capacitor has a high frequency (ESRCIN) of 150 mΩ and is measured with an impedance analyzer at 200
kHz. ESRCIN = 0.150 Ω
Estimate the CIN power dissipation (PCIN) using 方程式95:
2
PCIN = ICINRMS ´ESRCIN = 0.5W
(95)
And recalculate the remaining power budget using 方程式96:
P
= P
-PCIN » 6.0W
BUDGET
BUDGET
(96)
There is approximately 6.0 W that remains in the power budget for the current-sensing network, to bias the
control device, and for all resistors supporting the control device.
8.2.2.10 Current Sense Network (CT, RCS, R7, DA)
The CT chosen for this design has a turns ratio (CTRAT) of 100:1 in 方程式97:
IP
CTRAT
=
= 100
IS
(97)
(98)
Calculate nominal peak current (IP1) at VINMIN
:
The peak primary current is calculated using 方程式98:
æ
ç
è
ö
÷
ø
POUT
DILOUT
V
´DMAX
1
INMIN
I =
+
+
» 3.3A
P1
VOUT ´ h
2
a1 LMAG ´ 2´F
SW
The CS pin voltage where peak current limit will trip is:
