Return to the Summary Table.
图 7-144. FLAG_SHORT2 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
FLAG_SHORT FLAG_SHORT
RESERVED
R-0h
FLAG_SHORT FLAG_SHORT
OUTF1
OUTF0
OUTE1
OUTE0
R-0h
R-0h
R-0h
R-0h
表 7-152. FLAG_SHORT2 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
FLAG_SHORTOUTF1
R
0h
Output short-circuit fault flag for OUTF1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
4
FLAG_SHORTOUTF0
R
0h
Output short-circuit fault flag for OUTF0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
3-2
1
RESERVED
R
R
0h
0h
Reserved
FLAG_SHORTOUTE1
Output short-circuit fault flag for OUTE1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
0
FLAG_SHORTOUTE0
R
0h
Output short-circuit fault flag for OUTE0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
7.6.5.15 FLAG_SHORT3 Register (Offset = AEh) [Reset = 00h]
FLAG_SHORT3 is shown in 图 7-145 and described in 表 7-153.
Return to the Summary Table.
图 7-145. FLAG_SHORT3 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
FLAG_SHORT FLAG_SHORT
RESERVED
R-0h
FLAG_SHORT FLAG_SHORT
OUTH1
OUTH0
OUTG1
OUTG0
R-0h
R-0h
R-0h
R-0h
表 7-153. FLAG_SHORT3 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
FLAG_SHORTOUTH1
R
0h
Output short-circuit fault flag for OUTH1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
4
FLAG_SHORTOUTH0
R
0h
Output short-circuit fault flag for OUTH0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
3-2
1
RESERVED
R
R
0h
0h
Reserved
FLAG_SHORTOUTG1
Output short-circuit fault flag for OUTG1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
0
FLAG_SHORTOUTG0
R
0h
Output short-circuit fault flag for OUTG0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
