TPS7H5005-SEP, TPS7H5006-SEP, TPS7H5007-SEP, TPS7H5008-SEP
SLVSGG1 – FEBRUARY 2022
www.ti.com
(45)
(46)
(47)
(48)
(49)
(50)
IPRI _MAX (VIN _MIN ) IPRI _MIN (VIN _MIN )
mPRI
=
tON _MAX
(51)
(52)
9.27 A 6.73 A
0.63 s
A
= 4072130.16 = 4.07
A
mPRI
=
s
s
(53)
(54)
9.2.2.7 Main Switching FETs
In the push-pull topology, the switching devices on the primary side will see a voltage that is equal to twice that
of the input when the devices are off. As such, the GaN FETs selected should have a voltage rating that 3 times
higher than the input voltage. The voltage rating for the GaN FETs was conservatively chosen for the primary
