TMS320TCI6487
TMS320TCI6488
Communications Infrastructure Digital Signal Processor
SPRS358F–APRIL 2007–REVISED AUGUST 2008
www.ti.com
Table 8-4. EDMA3 Parameter RAM
HEX ADDRESS
02A0 4000 - 02A0 401F
02A0 4020 - 02A0 403F
02A0 4040 - 02A0 405F
02A0 4060 - 02A0 407F
02A0 4080 - 02A0 409F
02A0 40A0 - 02A0 40BF
02A0 40C0 - 02A0 40DF
02A0 40E0 - 02A0 40FF
02A0 4100 - 02A0 411F
02A0 4120 - 02A0 413F
...
ACRONYM
REGISTER NAME
Parameter Set 0
Parameter Set 1
Parameter Set 2
Parameter Set 3
Parameter Set 4
Parameter Set 5
Parameter Set 6
Parameter Set 7
Parameter Set 8
Parameter Set 9
...
02A0 47E0 - 02A0 47FF
02A0 4800 - 02A0 481F
02A0 4820 - 02A0 483F
...
Parameter Set 63
Parameter Set 64
Parameter Set 65
...
02A0 5FC0 - 02A0 5FDF
02A0 5FE0 - 02A0 5FFF
Parameter Set 254
Parameter Set 255
Table 8-5. EDMA3 Transfer Controller 0 Registers
HEX ADDRESS RANGE
02A2 0000
ACRONYM
PID
REGISTER NAME
Peripheral Identification Register
EDMA3TC Configuration Register
Reserved
02A2 0004
TCCFG
-
02A2 0008 - 02A2 00FC
02A2 0100
TCSTAT
-
EDMA3TC Channel Status Register
Reserved
02A2 0104 - 02A2 011C
02A2 0120
ERRSTAT
ERREN
ERRCLR
ERRDET
ERRCMD
-
Error Register
02A2 0124
Error Enable Register
02A2 0128
Error Clear Register
02A2 012C
Error Details Register
02A2 0130
Error Interrupt Command Register
Reserved
02A2 0134 - 02A2 013C
02A2 0140
RDRATE
-
Read Rate Register
02A2 0144 - 02A2 023C
02A2 0240
Reserved
SAOPT
SASRC
SACNT
SADST
SABIDX
SAMPPRXY
SACNTRLD
SASRCBREF
SADSTBREF
-
Source Active Options Register
Source Active Source Address Register
Source Active Count Register
Source Active Destination Address Register
Source Active Source B-Index Register
Source Active Memory Protection Proxy Register
Source Active Count Reload Register
Source Active Source Address B-Reference Register
Source Active Destination Address B-Reference Register
Reserved
02A2 0244
02A2 0248
02A2 024C
02A2 0250
02A2 0254
02A2 0258
02A2 025C
02A2 0260
02A2 0264 - 02A2 027C
02A2 0280
DFCNTRLD
DFSRCBREF
DFDSTBREF
-
Destination FIFO Set Count Reload
Destination FIFO Set Destination Address B Reference Register
Destination FIFO Set Destination Address B Reference Register
Reserved
02A2 0284
02A2 0288
02A2 028C - 02A2 02FC
94
