TMS320TCI6487
TMS320TCI6488
Communications Infrastructure Digital Signal Processor
www.ti.com
SPRS358F–APRIL 2007–REVISED AUGUST 2008
Table 5-12. Megamodule L1/L2 Memory Protection Registers (continued)
HEX ADDRESS
ACRONYM
L2MPPA8
REGISTER NAME
L2 Memory Protection Page Attribute Register 8
L2 Memory Protection Page Attribute Register 9
L2 Memory Protection Page Attribute Register 10
L2 Memory Protection Page Attribute Register 11
L2 Memory Protection Page Attribute Register 12
L2 Memory Protection Page Attribute Register 13
L2 Memory Protection Page Attribute Register 14
L2 Memory Protection Page Attribute Register 15
L2 Memory Protection Page Attribute Register 16
L2 Memory Protection Page Attribute Register 17
L2 Memory Protection Page Attribute Register 18
L2 Memory Protection Page Attribute Register 19
L2 Memory Protection Page Attribute Register 20
L2 Memory Protection Page Attribute Register 21
L2 Memory Protection Page Attribute Register 22
L2 Memory Protection Page Attribute Register 23
L2 Memory Protection Page Attribute Register 24
L2 Memory Protection Page Attribute Register 25
L2 Memory Protection Page Attribute Register 26
L2 Memory Protection Page Attribute Register 27
L2 Memory Protection Page Attribute Register 28
L2 Memory Protection Page Attribute Register 29
L2 Memory Protection Page Attribute Register 30
L2 Memory Protection Page Attribute Register 31
L2 Memory Protection Page Attribute Register 32
L2 Memory Protection Page Attribute Register 33
L2 Memory Protection Page Attribute Register 34
L2 Memory Protection Page Attribute Register 35
L2 Memory Protection Page Attribute Register 36
L2 Memory Protection Page Attribute Register 37
L2 Memory Protection Page Attribute Register 38
L2 Memory Protection Page Attribute Register 39
L2 Memory Protection Page Attribute Register 40
L2 Memory Protection Page Attribute Register 41
L2 Memory Protection Page Attribute Register 42
L2 Memory Protection Page Attribute Register 43
L2 Memory Protection Page Attribute Register 44
L2 Memory Protection Page Attribute Register 45
L2 Memory Protection Page Attribute Register 46
L2 Memory Protection Page Attribute Register 47
L2 Memory Protection Page Attribute Register 48
L2 Memory Protection Page Attribute Register 49
L2 Memory Protection Page Attribute Register 50
L2 Memory Protection Page Attribute Register 51
L2 Memory Protection Page Attribute Register 52
L2 Memory Protection Page Attribute Register 53
L2 Memory Protection Page Attribute Register 54
0184 A220
0184 A224
0184 A228
0184 A22C
0184 A230
0184 A234
0184 A238
0184 A23C
0184 A240
0184 A244
0184 A248
0184 A24C
0184 A250
0184 A254
0184 A258
0184 A25C
0184 A260
0184 A264
0184 A268
0184 A26C
0184 A270
0184 A274
0184 A278
0184 A27C
0184 A280
0184 A2834
0184 A288
0184 A28C
0184 A290
0184 A294
0184 A298
0184 A29C
0184 A2A0
0184 A2A4
0184 A2A8
0184 A2AC
0184 A2B0
0184 A2B4
0184 A2B8
0184 A2BC
0184 A2C0
0184 A2C4
0184 A2C8
0184 A2CC
0184 A2D0
0184 A2D4
0184 A2D8
L2MPPA9
L2MPPA10
L2MPPA11
L2MPPA12
L2MPPA13
L2MPPA14
L2MPPA15
L2MPPA16
L2MPPA17
L2MPPA18
L2MPPA19
L2MPPA20
L2MPPA21
L2MPPA22
L2MPPA23
L2MPPA24
L2MPPA25
L2MPPA26
L2MPPA27
L2MPPA28
L2MPPA29
L2MPPA30
L2MPPA31
L2MPPA32
L2MPPA33
L2MPPA34
L2MPPA35
L2MPPA36
L2MPPA37
L2MPPA38
L2MPPA39
L2MPPA40
L2MPPA41
L2MPPA42
L2MPPA43
L2MPPA44
L2MPPA45
L2MPPA46
L2MPPA47
L2MPPA48
L2MPPA49
L2MPPA50
L2MPPA51
L2MPPA52
L2MPPA53
L2MPPA54
Submit Documentation Feedback
C64x+ Megamodule
69
