SPRS358F–APRIL 2007–REVISED AUGUST 2008
Table 8-76. Semaphore Registers (continued)
HEX ADDRESS
02B4 0330
02B4 0334
02B4 0338
02B4 033C
02B4 0340
02B4 0344
02B4 0348
02B4 034C
02B4 0350
02B4 0354
02B4 0358
02B4 035C
02B4 0360
02B4 0364
02B4 0368
02B4 036C
02B4 0370
02B4 0374
02B4 0378
02B4 037C
02B4 0400
02B4 0404
02B4 0408
ACRONYM
SEM_QUERY12
SEM_QUERY13
SEM_QUERY14
SEM_QUERY15
SEM_QUERY16
SEM_QUERY17
SEM_QUERY18
SEM_QUERY19
SEM_QUERY20
SEM_QUERY21
SEM_QUERY22
SEM_QUERY23
SEM_QUERY24
SEM_QUERY25
SEM_QUERY26
SEM_QUERY27
SEM_QUERY28
SEM_QUERY29
SEM_QUERY30
SEM_QUERY31
SEM_FLAG0
REGISTER NAME
Semaphore Query12 Register
Semaphore Query13 Register
Semaphore Query14 Register
Semaphore Query15 Register
Semaphore Query16 Register
Semaphore Query17 Register
Semaphore Query18 Register
Semaphore Query19 Register
Semaphore Query20 Register
Semaphore Query21 Register
Semaphore Query22 Register
Semaphore Query23 Register
Semaphore Query24 Register
Semaphore Query25 Register
Semaphore Query26 Register
Semaphore Query27 Register
Semaphore Query28 Register
Semaphore Query29 Register
Semaphore Query30 Register
Semaphore Query31 Register
Semaphore Flag0 Register (for C64x+ Core0)
Semaphore Flag1 Register (for C64x+ Core1)
Semaphore Flag2 Register (for C64x+ Core2)
Reserved
SEM_FLAG1
SEM_FLAG2
02B4 040C - 02B4 047C
02B4 0480
Reserved
SEM_FLAG_SET0
SEM_FLAG_SET1
SEM_FLAG_SET2
Reserved
Semaphore Flag Set0 Register (for C64x+ Core0)
Semaphore Flag Set1 Register (for C64x+ Core1)
Semaphore Flag Set2 Register (for C64x+ Core2)
Reserved
02B4 0484
02B4 0488
02B4 048C - 02B4 04FF
02B4 0500
SEM_ERR
Semaphore Error Register
02B4 0504
SEM_ERR_CLR
Reserved
Semaphore Error Clear Register
Reserved
02B4 050C - 02B4 07FF
Submit Documentation Feedback
Peripheral Information and Electrical Specifications
183
