TMS320TCI6487
TMS320TCI6488
Communications Infrastructure Digital Signal Processor
SPRS358F–APRIL 2007–REVISED AUGUST 2008
www.ti.com
Table 8-78. Antenna Interface System Registers (continued)
HEX ADDRESS
02BC C080
ACRONYM
TM_LINK0_STS
REGISTER NAME
TX MAC Link 0 Status Register
02BC C084 - 02BC C7FC
02BC C800
TM_LINK1_0CFG
TX MAC Link 1 Configuration Register 0
TX MAC Link 1 Configuration Register 1
TX MAC Link 1 Configuration Register 2
Reserved
02BC C804
TM_LINK1_1CFG
02BC C808
TM_LINK1_2CFG
02BC C80C - 02BC C87C
02BC C880
-
TM_LINK1_STS
TX MAC Link 1 Status Register
Reserved
02BC C884 - 02BC CFFC
02BC D000
-
TM_LINK2_0CFG
TX MAC Link 2 Configuration Register 0
TX MAC Link 2 Configuration Register 1
TX MAC Link 2 Configuration Register 2
Reserved
02BC D004
TM_LINK2_1CFG
02BC D008
TM_LINK2_2CFG
02BC D00C - 02BC D07C
02BC D080
-
TM_LINK2_STS
TX MAC Link 2 Status Register
Reserved
02BC D08C - 02BC D7FC
02BC D800
-
TM_LINK3_0CFG
TX MAC Link 3 Configuration Register 0
TX MAC Link 3 Configuration Register 1
TX MAC Link 3 Configuration Register 2
Reserved
02BC D804
TM_LINK3_1CFG
02BC D808
TM_LINK3_2CFG
02BC D80C - 02BC D87C
02BC D880
-
TM_LINK3_STS
TX MAC Link 3 Status Register
Reserved
02BC D884 - 02BC DFFC
02BC E000
-
TM_LINK4_0CFG
TM_LINK4_1CFG
TM_LINK4_2CFG
-
TX MAC Link 4 Configuration Register 0
TX MAC Link 4 Configuration Register 1
TX MAC Link 4 Configuration Register 2
Reserved
02BC E004
02BC E008
02BC E00C - 02BC E07C
02BC E080
TM_LINK4_STS
-
TX MAC Link 4 Status Register
Reserved
02BC E084 - 02BC E7FC
02BC E800
TM_LINK5_0CFG
TM_LINK5_1CFG
TM_LINK5_2CFG
-
TX MAC Link 5 Configuration Register 0
TX MAC Link 5 Configuration Register 1
TX MAC Link 5 Configuration Register 2
Reserved
02BC E804
02BC E808
02BC E80C - 02BC E87C
02BC E880
TM_LINK5_STS
-
TX MAC Link 5 Status Register
Reserved
02BC E884 - 02BC FFFC
02BD 0000 - 02BD 3FFC
02BD 4000
-
Reserved
AG_LINK0_CFG
AG_LINK0_STS
AG_LINK0_HDR_ERR_STSA
AG_LINK0_HDR_ERR_STSB
AG_LINK0_HDR_ERR_STSC
AG_LINK0_HDR_ERR_STSD
-
AG Link 0 Configuration Register
AG Link 0 Status Register
02BD 4004
02BD 4008
AG Link 0 Header Error Status Register 0
AG Link 0 Header Error Status Register 1
AG Link 0 Header Error Status Register 2
AG Link 0 Header Error Status Register 3
Reserved
02BD 400C
02BD 4010
02BD 4014
02BD 4018 - 02BD 47FC
02BD 4800
AG_LINK1_CFG
AG_LINK1_STS
AG_LINK1_HDR_ERR_STSA
AG_LINK1_HDR_ERR_STSB
AG_LINK1_HDR_ERR_STSC
AG_LINK1_HDR_ERR_STSD
-
AG Link 1 Configuration Register
AG Link 1 Status Register
02BD 4804
02BD 4808
AG Link 1 Header Error Status Register 0
AG Link 1 Header Error Status Register 1
AG Link 1 Header Error Status Register 2
AG Link 1 Header Error Status Register 3
Reserved
02BD 480C
02BD 4810
02BD 4814
02BD 4818 - 02BD 4FFC
186
Peripheral Information and Electrical Specifications
