7.27.2 Trace
The C6678 device supports Trace. Trace is a debug technology that provides a detailed, historical account of
application code execution, timing, and data accesses. Trace collects, compresses, and exports debug information
for analysis. Trace works in real-time and does not impact the execution of the system.
For more information on board design guidelines for Trace Advanced Emulation, see the 60-Pin Emulation Header
Technical Reference in ‘‘Related Documentation from Texas Instruments’’ on page 73.
7.27.2.1 Trace Electrical Data/Timing
(1)
Table 7-88
(see Figure 7-61)
DSP Trace Switching Characteristics
No.
Parameter
Pulse duration, EMUn high detected at 50% Voh
tw(EMUnH)90% Pulse duration, EMUn high detected at 90% Voh
Min Max Unit
1
1
2
2
3
tw(EMUnH)
2.4
1.5
2.4
1.5
-1
ns
ns
tw(EMUnL)
Pulse duration, EMUn low detected at 50% Voh
Pulse duration, EMUn low detected at 10% Voh
Output skew time, time delay difference between EMUn pins configured as trace
Output slew rate EMUn
ns
tw(EMUnL)10%
tsko(EMUn)
ns
1
ns
t
sldp_(EMUn)
3.3
V/ns
End of Table 7-88
1 Over recommended operating conditions.
(1)
Table 7-89
(see Figure 7-61)
STM Trace Switching Characteristics
No.
Parameter
Min Max Unit
1
1
2
2
3
tw(EMUnH)
Pulse duration, EMUn high detected at 50% Voh with 60/40 duty cycle
Pulse duration, EMUn high detected at 90% Voh
4
3.5
4
ns
ns
tw(EMUnH)90%
tw(EMUnL)
Pulse duration, EMUn low detected at 50% Voh with 60/40 duty cycle
Pulse duration, EMUn low detected at 10% Voh
ns
tw(EMUnL)10%
tsko(EMUn)
3.5
-1
ns
Output skew time, time delay difference between EMUn pins configured as trace
Output slew rate EMUn
1
ns
t
sldp_(EMUn)
3.3
V/ns
End of Table 7-89
1 Over recommended operating conditions.
Figure 7-61
Trace Timing
1
2
EMUx
3
EMUy
3
EMUz
EMUx represents the EMU output pin configured as the trace clock output.
EMUy and EMUz represent all of the trace output data pins.
