7.5.2 PLL Controller Memory Map
The memory map of the PLL Controller is shown in Table 7-14. TMS320C6678-specific PLL Controller register
definitions can be found in the sections following Table 7-14. For other registers in the table, see the Phase Locked
Loop (PLL) for KeyStone Devices User Guide in ‘‘Related Documentation from Texas Instruments’’ on page 73.
CAUTION—Note that only registers documented here are accessible on the TMS320C6678. Other addresses
in the PLL Controller memory map including the reserved registers should not be modified. Furthermore,
only the bits within the registers described here are supported. Avoid writing to any reserved memory
location or changing the value of reserved bits. It is recommended to use read-modify-write sequence to
make any changes to the valid bits in the register.
Table 7-14
PLL Controller Registers (Including Reset Controller) (Part 1 of 2)
Hex Address Range
0231 0000 - 0231 00E3
0231 00E4
Field
-
Register Name
Reserved
RSTYPE
RSTCTRL
RSTCFG
RSISO
-
Reset Type Status Register (Reset Controller)
Software Reset Control Register (Reset Controller)
Reset Configuration Register (Reset Controller)
Reset Isolation Register (Reset Controller)
Reserved
0231 00E8
0231 00EC
0231 00F0
0231 00F0 - 0231 00FF
0231 0100
PLLCTL
-
PLL Control Register
Reserved
0231 0104
0231 0108
SECCTL
-
PLL Secondary Control Register
Reserved
0231 010C
0231 0110
PLLM
-
PLL Multiplier Control Register
Reserved
0231 0114
0231 0118
PLLDIV1
PLLDIV2
PLLDIV3
-
Reserved
0231 011C
PLL Controller Divider 2 Register
Reserved
0231 0120
0231 0124
Reserved
0231 0128
-
Reserved
0231 012C - 0231 0134
0231 0138
-
Reserved
PLLCMD
PLLSTAT
ALNCTL
DCHANGE
CKEN
CKSTAT
SYSTAT
-
PLL Controller Command Register
PLL Controller Status Register
PLL Controller Clock Align Control Register
PLLDIV Ratio Change Status Register
Reserved
0231 013C
0231 0140
0231 0144
0231 0148
0231 014C
Reserved
0231 0150
SYSCLK Status Register
Reserved
0231 0154 - 0231 015C
0231 0160
PLLDIV4
PLLDIV5
PLLDIV6
PLLDIV7
PLLDIV8
Reserved
0231 0164
PLL Controller Divider 5 Register
Reserved
0231 0168
0231 016C
Reserved
0231 0170
PLL Controller Divider 8 Register
