TMP435
www.ti.com
SBOS495A –MARCH 2010–REVISED APRIL 2010
DEVICE INFORMATION
DGS PACKAGE
MSOP-10
(TOP VIEW)
V+
DXP
DXN
A0
1
2
3
4
5
10 SCL
9
8
7
6
SDA
ALERT/THERM2
THERM
GND
A1
PIN ASSIGNMENTS
TMP435
NAME
NO.
1
DESCRIPTION
V+
DXP
Positive supply (2.7V to 5.5V)
2
Positive connection to remote temperature sensor
Negative connection to remote temperature sensor
Address pin 0
3
DXN
4
A0
5
A1
Address pin 1
6
GND
Ground
7
THERM
ALERT/THERM2
SDA
Thermal flag, active low, open-drain; requires pull-up resistor to V+
8
Alert (reconfigurable as second thermal flag), active low, open-drain; requires pull-up resistor to V+
Serial data line for SMBus, open-drain; requires pull-up resistor to V+
9
10
SCL
Serial clock line for SMBus, open-drain; requires pull-up resistor to V+
