PARAMETER MEASUREMENT INFORMATION (continued)
VCC
A
B
VO
0 V or 1.5 V
1.5 V or 0 V
1 kW ± 1%
CL = 15 pF ±20%
R
S1
RE
CL Includes Fixture
and Instrumentation
Capacitance
Input
Generator
50 W
VI
3 V
VI
50%
0 V
tPZH(2)
VOH
A at 1.5 V
B at 0 V
S1 to GND
VO
50%
GND
VCC
tPZL(2)
A at 0 V
B at 1.5 V
S1 to VCC
VO
50%
VOL
S0308-01
Figure 8. Measurement of Receiver Enable Times with Driver Disabled
