PARAMETER MEASUREMENT INFORMATION (continued)
3 V
DE
VCC
A
B
VO
1 kW ± 1%
CL = 15 pF ±20%
R
D
0 V or 3 V
S1
RE
CL Includes Fixture
and Instrumentation
Capacitance
Input
Generator
50 W
VI
3 V
VI
50%
50%
0 V
tPZH(1)
tPHZ
VOH
D at 3 V
S1 to GND
90%
VO
50%
» 0 V
tPZL(1)
tPLZ
VCC
D at 0 V
S1 to VCC
VO
50%
10%
VOL
S0307-01
Figure 7. Measurement of Receiver Enable/Disable Times with Driver Enabled
