4.9.3 Special Consideration for CPU Access Errors Resulting in Imprecise Aborts
Any CPU write access to a Normal or Device type memory, which generates a fault, will generate an
imprecise abort. The imprecise abort exception is disabled by default and must be enabled for the CPU to
handle this exception. The imprecise abort handling is enabled by clearing the "A" bit in the CPU’s
program status register (CPSR).
4.9.4 Master/Slave Access Privileges
The table below lists the access permissions for each bus master on the device. A bus master is a module
that can initiate a read or a write transaction on the device.
Each slave module on the main interconnect is listed in the table. A "Yes" indicates that the module listed
in the "MASTERS" column can access that slave module.
Table 4-22. Master / Slave Access Matrix
MASTERS
ACCESS MODE
SLAVES ON MAIN SCR
CRC
Flash Module
Bus2 Interface:
OTP, ECC, Bank
7
Non-CPU
Accesses to
Program Flash
and CPU Data
RAM
EMIF, Ethernet,
USB Slave
Peripheral
Control
Interfaces
Registers, All
Peripheral
Memories, And
All System
Module Control
Registers And
Memories
CPU READ
CPU WRITE
DMA
User/Privilege
User/Privilege
User
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
No
POM
User
DAP
Privilege
Privilege
Privilege
User
HTU1
HTU2
No
EMAC
OHCI
No
User
No
No
No
4.9.5 Special Notes on Accesses to Certain Slaves
Write accesses to the Power Domain Management Module (PMM) control registers are limited to the CPU
(master id = 1). The other masters can only read from these registers.
A debugger can also write to the PMM registers. The master-id check is disabled in debug mode.
The device contains dedicated logic to generate a bus error response on any access to a module that is in
a power domain that has been turned OFF.
4.9.6 Parameter Overlay Module (POM) Considerations
•
The POM can map onto up to 8MB of the internal or external memory space. The starting address and
the size of the memory overlay are configurable via the POM control registers. Care must be taken to
ensure that the overlay is mapped on to available memory.
•
•
ECC must be disabled by software via CP15 in case POM overlay is enabled; otherwise ECC errors
will be generated.
POM overlay must not be enabled when the flash and internal RAM memories are swapped via the
MEM SWAP field of the Bus Matrix Module Control Register 1 (BMMCR1).
