PGA400-Q1
www.ti.com
SLDS186 –MARCH 2012
5 ELECTRICAL CHARACTERISTICS
5.1 Overvoltage Protection
PARAMETER
TEST CONDITIONS
MIN
TYP
6.1
MAX
UNIT
V
OV
Overvoltage protection threshold
Overvoltage protection hysteresis
5.5
7.0
OVhyst
410
mV
5.2 Regulators
PARAMETER
AVDD voltage
TEST CONDITIONS
CAVDD = 100 nF
MIN
TYP
MAX
UNIT
V
VAVDD
3.3
I_AVDD
AVDD current
VAVDD = 3.3 V
5
mA
V
No EEPROM Programming
EEPROM Programming
3.3
3.6
VDVDD
DVDD voltage
V
5.3 Internal Oscillator and External Crystal Interface
PARAMETER
INTERNAL OSCILLATOR
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Internal Oscillator frequency
Internal Oscillator frequency
Tamb = 25 °C
38.4
36.3
40
41.6
43.7
MHz
MHz
Accross operating temperature
EXTERNAL 40-MHZ CRYSTAL
Low-level input voltage on XTAL
High-level input voltage on XTAL
–0.3
0.1× VDD
VDD + 0.3
V
V
0.7 × VDD
Copyright © 2012, Texas Instruments Incorporated
ELECTRICAL CHARACTERISTICS
5
Submit Documentation Feedback
Product Folder Link(s): PGA400-Q1
