Register 26h, AUTO Source Selector Cause Setting
(Address: 26h, Write and Read)
DATA
B7
B6
AERROR
0
B5
RSV
0
B4
AFSLMT
0
B3
ANPCM
0
B2
AVALID
0
B1
RSV
0
B0
AUNLOCK
1
Reg Name
Default Value
Memo
ACKSL
0
The AUTO source selector is an automatic selector that outputs DIR or ADC output based on the following
register settings. The following AUTO Source Selector Cause Setting registers are independent of the ERROR
Cause Setting Register (Register 25h).
ACKSL: ADC Output Clock Select
0: ADC clock selected by the ADCLK[2:0] Register (Register 42h) (default)
1: XTI clock
AERROR: ERROR
0: Not selected (default)
1: Selected
ERROR condition is defined by the ERROR Cause Setting Register (Register 25h).
AFSLMT: Limiting Acceptable Sampling Frequency
0: Not selected (default)
1: Selected
The definition of receivable sampling frequency range depends on the fS Limit Setting Register.
ANPCM: Non-PCM
0: Not selected (default)
1: Selected
The definition of Non PCM is depend on the Non-PCM Definition Setting Register.
AVALID: Validity Flag
0: Not selected (default)
1: Selected
AUNLOCK: PLL Lock Error
0: Not selected
1: Selected (default)
