PCM9211
www.ti.com
SBAS495 –JUNE 2010
Register 25h, ERROR Cause Setting
(Address: 25h, Write and Read)
DATA
Reg Name
Default Value
Memo
B7
RSV
0
B6
RSV
0
B5
EFSCHG
0
B4
EFSLMT
0
B3
ENPCM
0
B2
EVALID
0
B1
EPARITY
0
B0
EUNLOCK
1
The following ERROR Cause Setting registers are independent of the AUTO Source Selector Cause Setting
Register (Register 26h).
EFSCHG: DIR Sampling Frequency Change
0: Not selected (default)
1: Selected
EFSLMT: DIR Limiting Acceptable Sampling Frequency
0: Not selected (default)
1: Selected
The definition of receivable sampling frequency range depends on the fS Limit Setting Register.
ENPCM: Non-PCM
0: Not selected (default)
1: Selected
The definition of non-PCM is depend on the Non-PCM Definition Setting Register.
EVALID: Validity Flag
0: Not selected (default)
1: Selected
EPARITY: Parity Error
0: Not selected (default)
1: Selected
EUNLOCK: PLL Lock Error
0: Not selected
1: Selected (default)
This register is used for setting the ERROR output factor.
The required factors of ERROR set to '1' are selected based on OR logic.
