Table 2–11. Miscellaneous Terminals
TERMINAL
PCM
I/O
DESCRIPTION
PGF
NAME
NUMBER NUMBER
GOZ
NO/HSLED
MS0
63
62
69
68
I
NAND tree enable pin.
I/O
I
NAND tree out when GOZ is asserted. Hot-swap LED when GOZ is deasserted.
Mode select 0
120
132
Mode select 1 when mode select 0 is low, bus power clock control when mode select 0 is
high.
MS1/BPCC
P_MFUNC
S_MFUNC
159
102
5
174
112
7
I
Primary multifunction terminal. This terminal can be configured as P_CLKRUN, P_LOCK,
or HS_ENUM depending on the values of MS0 and MS1.
I/O
I/O
Secondary multifunction terminal. This terminal can be configured as S_CLKRUN,
S_LOCK, or HS_SWITCH depending on the values of MS0 and MS1.
Table 2–12. Power Supply
TERMINAL
DESCRIPTION
PGF NUMBER
NAME
PCM NUMBER
1, 12, 19, 27, 34, 41, 50, 54, 1, 14, 21, 29, 36, 45, 56, 60,
58, 65, 71, 81, 86, 94, 103, 64, 71, 77, 89, 96, 104, 113,
GND
Device ground terminals
112, 119, 121, 128, 135,
143, 151, 157
122, 130, 133, 142, 149,
157, 165, 171
8, 15, 23, 30, 40, 46, 56, 60,
75, 80, 90, 98, 108, 116,
125, 131, 139, 147, 154,
160
10, 17, 25, 32, 44, 52, 62,
66, 81, 88, 100, 108, 118,
126, 139, 145, 153, 161,
168, 176
V
CC
Power-supply terminal for core logic (3.3 V)
Primary bus-signaling environment supply. P_V
protection circuitry on primary bus I/O signals.
is used in
is used in
CCP
P_V
S_V
67
52
73
58
CCP
Secondary bus-signaling environment supply. S_V
protection circuitry on secondary bus I/O signals.
CCP
CCP
2–12
