LM158, LM158A, LM258, LM258A
LM358, LM358A, LM358Y, LM2904, LM2904Q
DUAL OPERATIONAL AMPLIFIERS
SLOS068C – JUNE 1976 – REVISED JULY 1998
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
LM158, LM158A
LM2904
LM258, LM258A
LM358, LM358A
UNIT
LM2904Q
Supply voltage, V
(see Note 1)
32
±32
26
±26
V
V
V
CC
Differential input voltage, V (see Note 2)
ID
Input voltage, V (either input)
I
–0.3 to 32
–0.3 to 26
Duration of output short circuit (one amplifier) to ground
Unlimited
Unlimited
at (or below) 25°C free-air temperature (V
≤ 15 V) (see Note 3)
CC
Continuous total power dissipation
See Dissipation Rating Table
–55 to 125
LM158, LM158A
LM258, LM258A
LM358, LM358A
LM2904, LM2904Q
–25 to 85
0 to 70
Operating free-air temperature range, T
°C
A
–40 to 125
–65 to 150
Storage temperature range, T
stg
–65 to 150
260
°C
°C
°C
°C
Case temperature for 60 seconds
FK package
Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds
JG package
300
300
260
D, P, or PW package
260
NOTES: 1. All voltage values, except differential voltages and V
terminal.
specified for measurement of I , are with respect to the network ground
OS
CC
2. Differential voltages are at IN+ with respect to IN–.
3. Short circuits from outputs to V
CC
can cause excessive heating and eventual destruction.
DISSIPATION RATING TABLE
T
≤ 25°C
DERATING FACTOR
T
= 70°C
T
= 85°C
T = 125°C
A
A
A
A
PACKAGE
POWER RATING
ABOVE T = 25°C
POWER RATING POWER RATING POWER RATING
A
D
FK
JG
P
725 mW
5.8 mW/°C
11.0 mW/°C
8.4 mW/°C
8.0 mW/°C
4.2 mW/°C
464 mW
880 mW
672 mW
640 mW
336 mW
377 mW
715 mW
546 mW
520 mW
273 mW
145 mW
275 mW
210 mW
200 mW
–
1375 mW
1050 mW
1000 mW
525 mW
PW
4
