3.3.21 Timer
Table 3-46. Timer Terminal Functions
SIGNAL NAME [1]
DESCRIPTION [2]
TYPE [3]
I/O
AAR BALL [4]
TIM2_IO
TIM3_IO
TIM4_IO
TIM5_IO
TIM6_IO
TIM7_IO
Timer 2 capture event input or PWM output
Timer 3 capture event input or PWM output
Timer 4 capture event input or PWM output
Timer 5 capture event input or PWM output
Timer 6 capture event input or PWM output
Timer 7 capture event input or PWM output
AF27, AG1, M3
AG30, AJ31, M5
AB9, G28, N2
AA10, R8, U28
AE1, F1, Y3
I/O
I/O
I/O
I/O
I/O
AD2, C20, Y11
