3.3.19 SPI
www.ti.com
3.3.19.1 SPI 0
Table 3-41. SPI 0 Terminal Functions
SIGNAL NAME [1]
DESCRIPTION [2]
TYPE [3]
AAR BALL [4]
SPI[0]_D[0]
SPI[0]_D[1]
SPI[0]_SCLK
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
J28
J27
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
SPI Clock I/O
I/O
I/O
I/O
I/O
I/O
N24
G29
G28
E29
E31
SPI[0]_SCS[0]
SPI[0]_SCS[1]
SPI[0]_SCS[2]
SPI[0]_SCS[3]
SPI Chip Select I/O
SPI Chip Select I/O
SPI Chip Select I/O
SPI Chip Select I/O
3.3.19.2 SPI 1
Table 3-42. SPI 1 Terminal Functions
SIGNAL NAME [1]
DESCRIPTION [2]
TYPE [3]
AAR BALL [4]
SPI[1]_D[0]
SPI[1]_D[1]
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
N23
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
M27
SPI[1]_SCLK
SPI[1]_SCS[0]
SPI[1]_SCS[1]
SPI[1]_SCS[2]
SPI[1]_SCS[3]
SPI Clock I/O
I/O
I/O
I/O
I/O
I/O
M29
J29
SPI Chip Select I/O
SPI Chip Select I/O
SPI Chip Select I/O
SPI Chip Select I/O
U28
D31
D30
3.3.19.3 SPI 2
Table 3-43. SPI 2 Terminal Functions
SIGNAL NAME [1]
DESCRIPTION [2]
TYPE [3]
AAR BALL [4]
SPI[2]_D[0]
SPI[2]_D[1]
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
AK6, M8, N1
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
AL6, L6, N2
SPI[2]_SCLK
SPI[2]_SCS[0]
SPI[2]_SCS[1]
SPI[2]_SCS[2]
SPI[2]_SCS[3]
SPI Clock I/O
I/O
I/O
I/O
I/O
I/O
AJ6, L4, R8
SPI Chip Select I/O
SPI Chip Select I/O
SPI Chip Select I/O
SPI Chip Select I/O
AF2
N9
L2
AK5
3.3.19.4 SPI 3
Table 3-44. SPI 3 Terminal Functions
SIGNAL NAME [1]
DESCRIPTION [2]
TYPE [3]
AAR BALL [4]
SPI[3]_D[0]
SPI[3]_D[1]
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
A5, F5, M10
SPI Data I/O. Can be configured as either MISO or
MOSI.
I/O
A6, E2, L12
90
