DM385, DM388
www.ti.com
SPRS821D –MARCH 2013–REVISED DECEMBER 2013
Table 7-3. Device Operating Points (OPPs)
CORE LOGIC VOLTAGE DOMAINS
CORE
ARM
HDVICP2
L3/L4,
Core
(MHz)
Cortex A8
(MHz)
HDVPSS
(MHz)
ISS
(MHz)
Media Ctlr.
(MHz)
DDR
OPP
HDVICP2
(MHz)(1)
100%(1.1 V)
600
720
220
290
410
450
200
200
240
260
400
400
480
560
200
200
240
280
200
200
240
240
400
400
533
533
(AAR0x)(2)
120% (1.2 V)
(AAR0x)
Turbo (1.35 V)
(AAR1x)
970
Nitro (1.35 V)
(AAR2x)
1000
(1) All DDR access must be suspended prior to changing the DDR frequency of operation.
(2) OPP100 is currently supported only on DM388 commercial temperature devices.
Although the OPP for each Core Logic Voltage Domain is independently selectable, not all combinations
of OPPs are supported. Table 7-4 marks the supported ARM OPPs for a given CORE OPP.
Table 7-4. Supported OPP Combinations(1)
ARM
HDVICP2
OPP120
CORE
Nitro
Nitro
X
Turbo
X
OPP120
X
OPP100(2)
Nitro
X
Turbo
X
OPP100(2)
Turbo
OPP120
OPP100(2)
X
X
X
X
X
(1) "X" denotes supported combinations.
(2) OPP100 is currently only supported on DM388 commercial temperature devices.
7.2.2.2 Adaptive Voltage Scaling [Currently Not Supported]
As mentioned in Section 7.2.2.1, Dynamic Voltage Frequency Scaling (DVFS) above, every OPP has an
associated voltage range. Based on the silicon process, temperature, and chosen OPP, the SmartReflex
modules guide software in adjusting the Core Logic Voltage Domain supply voltage (CVDD) within these
ranges. This technique is called Adaptive Voltage Scaling (AVS). AVS occurs continuously and in real-
time, helping to minimize power consumption in response to changing operating conditions.
7.2.3 Memory Power Management
In order to reduce SRAM leakage, many SRAM blocks can be switched from ACTIVE mode to
SHUTDOWN mode. When SRAM is put in SHUTDOWN mode, the voltage supplied to it is automatically
removed and all data in that SRAM is lost.
All SRAM located in a switchable power domain (all domains except ALWAYS_ON) automatically enters
SHUTDOWN mode whenever its associated power domain goes into the "OFF" state. The SRAM returns
to the ACTIVE state when the corresponding Power Domain returns to the "ON" state.
In addition, the following SRAM within the ALWAYS_ON Power Domain can also be independently put
into SHUTDOWN by programming the x_MEM_PWRDN registers in the Control Module:
•
•
Media Controller SRAM
OCMC SRAM
7.2.4 SERDES_CLKP/N LDO
The SERDES_CLKP/N input buffers are powered by an internal LDO which is programmed through the
REFCLK_LJCBLDO_CTRL register in the Control Module.
