bq24707
bq24707A
SLUSA78B –JULY 2010–REVISED MARCH 2011
www.ti.com
TYPICAL CHARACTERISTICS
Table 1. Table of Graphs
FIGURE NO.
VCC, ACDET, REGN and ACOK Power up (bq24707)
Charge Enable by ILIM
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
Figure 8
Figure 9
Figure 10
Figure 11
Figure 12
Figure 13
Figure 14
Current Soft-start
Charge Disable by ILIM
Continuous Conduction Mode Switching Waveforms
Cycle-by-Cycle Synchronous to Non-synchronous
100% Duty and Refresh Pulse
System Load Transient (Input DPM)
Battery Insertion
Battery to Ground Short Protection
Battery to Ground Short Transition
Efficiency vs Output Current
CH1: VCC, 10V/div, CH2: ACDET, 2V/div, CH3: ACOK, 5V/div,
CH4: REGN, 5V/div, 200ms/div
CH2: ILIM, 1V/div, CH4: inductor current, 1A/div, 10ms/div
Figure 3. VCC, ACDET, REGN and ACOK Power Up
(bq24707)
Figure 4. Charge Enable by ILIM
CH1: PHASE, 10V/div, CH2: Vin, 10V/div, CH3: LODRV, 5V/div,
CH4: inductor current, 2A/div, 2ms/div
CH2: ILIM, 1V/div, CH4: inductor current, 1A/div, 4us/div
Figure 5. Current Soft-Start
Figure 6. Charge Disable by ILIM
8
Submit Documentation Feedback
© 2010–2011, Texas Instruments Incorporated
Product Folder Link(s): bq24707 bq24707A
