表6-49. CPTS0 Signal Descriptions (continued)
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
A22
[3]
CPTS Time Stamp Generator Bit 1 from Time Sync
Router
SYNC1_OUT
SYNC2_OUT
SYNC3_OUT
O
O
O
CPTS Time Stamp Generator Bit 2 from Time Sync
Router
AE18
CPTS Time Stamp Generator Bit 3 from Time Sync
Router
AH17
6.3.19 OLDI
6.3.19.1 MAIN Domain
表6-50. OLDI0 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
[3]
OLDI0_CLKN
OLDI0_CLKP
OLDI0_A0N
OLDI0_A0P
OLDI0_A1N
OLDI0_A1P
OLDI0_A2N
OLDI0_A2P
OLDI0_A3N
OLDI0_A3P
OLDI Differential Clock (negative)
OLDI Differential Clock (positive)
OLDI Differential Data (negative)
OLDI Differential Data (positive)
OLDI Differential Data (negative)
OLDI Differential Data (positive)
OLDI Differential Data (negative)
OLDI Differential Data (positive)
OLDI Differential Data (negative)
OLDI Differential Data (positive)
IO
IO
IO
IO
IO
IO
IO
IO
IO
IO
L25
K25
J28
K28
L27
K27
K24
J24
J26
K26
