表6-40. MCSPI0 Signal Descriptions (continued)
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
[3]
SPI0_CS1
SPI0_CS2
SPI0_CS3
SPI0_D0
SPI0_D1
SPI Chip Select 1
SPI Chip Select 2
SPI Chip Select 3
SPI Data 0
IO
IO
IO
IO
IO
AF13
AG11
AD11
AE13
AD13
SPI Data 1
表6-41. MCSPI1 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
SIGNAL NAME [1]
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
[3]
SPI1_CLK
SPI1_CS0
SPI1_CS1
SPI1_CS2
SPI1_CS3
SPI1_D0
SPI Clock
IO
IO
IO
IO
IO
IO
IO
AH12
AD12
AG12
AD18
AH18
AE12
AF12
SPI Chip Select 0
SPI Chip Select 1
SPI Chip Select 2
SPI Chip Select 3
SPI Data 0
SPI1_D1
SPI Data 1
表6-42. MCSPI2 Signal Descriptions
PIN TYPE
DESCRIPTION [2]
BALL [4]
[3]
SPI2_CLK
SPI2_CS0
SPI2_CS1
SPI2_CS2
SPI2_CS3
SPI2_D0
SPI Clock
IO
IO
IO
IO
IO
IO
IO
AE23
AD23
AF26
AH25
AF24
AD22
AC21
SPI Chip Select 0
SPI Chip Select 1
SPI Chip Select 2
SPI Chip Select 3
SPI Data 0
SPI2_D1
SPI Data 1
表6-43. MCSPI3 Signal Descriptions
PIN TYPE
DESCRIPTION [2]
BALL [4]
[3]
SPI3_CLK
SPI3_CS0
SPI3_CS1
SPI3_CS2
SPI3_CS3
SPI3_D0
SPI Clock
IO
IO
IO
IO
IO
IO
IO
Y27
W28
V26
U25
Y28
Y26
W26
SPI Chip Select 0
SPI Chip Select 1
SPI Chip Select 2
SPI Chip Select 3
SPI Data 0
SPI3_D1
SPI Data 1
6.3.16.2 MCU Domain
表6-44. MCSPI0 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
[3]
MCU_SPI0_CLK
MCU_SPI0_CS0
MCU_SPI0_CS1
MCU_SPI0_CS2
SPI Clock
IO
IO
IO
IO
Y1
Y4
P1
N3
SPI Chip Select 0
SPI Chip Select 1
SPI Chip Select 2
