AM6548, AM6528, AM6526
ZHCSLA7B –DECEMBER 2019 –REVISED JUNE 2021
www.ti.com.cn
表6-44. MCSPI0 Signal Descriptions (continued)
PIN TYPE
SIGNAL NAME [1]
MCU_SPI0_CS3
DESCRIPTION [2]
BALL [4]
[3]
SPI Chip Select 3
SPI Data 0
IO
IO
IO
AC3
Y3
MCU_SPI0_D0
MCU_SPI0_D1
SPI Data 1
Y2
表6-45. MCSPI1 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
[3]
MCU_SPI1_CLK
MCU_SPI1_CS0
MCU_SPI1_CS1
MCU_SPI1_CS2
MCU_SPI1_CS3
MCU_SPI1_D0
MCU_SPI1_D1
SPI Clock
IO
IO
IO
IO
IO
IO
IO
AF4
AD1
P4
SPI Chip Select 0
SPI Chip Select 1
SPI Chip Select 2
SPI Chip Select 3
SPI Data 0
P5
AD3
AF3
AE3
SPI Data 1
6.3.17 MMCSD
6.3.17.1 MAIN Domain
表6-46. MMCSD0 Signal Descriptions
PIN TYPE
SIGNAL NAME[1]
DESCRIPTION[2]
BALL [4]
[3]
MMC0_CLK(1) (2)
MMC0_CMD(1) (2)
MMC0_DS
MMC/SD Clock
MMC/SD Command
MMC Data Strobe
SD Card Detect (active low)
SD Write Protect
MMC/SD Data
O
IO
I
B25
B27
C25
A23
B23
A26
E25
C26
A25
E24
A24
B26
D25
MMC0_SDCD
I
MMC0_SDWP
MMC0_DAT0(1) (2)
MMC0_DAT1(1) (2)
I
IO
IO
IO
IO
IO
IO
IO
IO
MMC/SD Data
(2)
MMC0_DAT2(1)
MMC/SD Data
MMC0_DAT3(1) (2)
MMC0_DAT4(1) (2)
MMC0_DAT5(1) (2)
MMC0_DAT6(1) (2)
MMC0_DAT7(1) (2)
MMC/SD Data
MMC/SD Data
MMC/SD Data
MMC/SD Data
MMC/SD Data
(1) When MMCSD0 or MMCSD1 is used, any non-MMC signal function multiplexed with the respective pins are not available. This is due
to the MMC having an internal IO multiplexer which is controlled by MMCSD0/1_SS_PHY_CTRL_1_REG[31] IOMUX_ENABLE. This
internal IO multiplexer is primary for the signal functions associated with MMCSD pins, and the PADCONFIG’s MUXMODE is
secondary. Additionally, the internal IO multiplexer affects all of the MMCSD0 or MMCSD1 pins, regardless of configured data bus
width. Therefore, when MMCSD0/1_SS_PHY_CTRL_1_REG[31] IOMUX_ENABLE = 0, the respective MMCSD pins are configured for
eMMC/SD functionality, regardless of the PADCONFIG [MUXMODE] setting.
(2) Each of these signals should have an external 50kΩpull-up resistor connected to the corresponding power supply.
表6-47. MMCSD1 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
MMC1_CLK(1) (2)
DESCRIPTION [2]
BALL [4]
[3]
O
IO
I
MMC/SD Clock
C27
C28
B24
MMC1_CMD(1) (2)
MMC/SD Command
MMC1_SDCD
SD Card Detect (active low)
