2.3.6 Serial Communication Interfaces
2.3.6.1 CAN
www.ti.com
Table 2-44. CAN/DCAN0 Signals Description
TYPE
[3]
SIGNAL NAME [1]
DESCRIPTION [2]
ZCE BALL [4]
ZCZ BALL [4]
dcan0_rx
dcan0_tx
DCAN0 Receive Data
DCAN0 Transmit Data
I
D19, F17, N18
E17, E19, M17
D17, E16, K15
D18, E15, J18
O
Table 2-45. CAN/DCAN1 Signals Description
TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
[3]
ZCE BALL [4]
ZCZ BALL [4]
dcan1_rx
dcan1_tx
DCAN1 Receive Data
DCAN1 Transmit Data
I
C19, F18, G17
D18, F19, G19
D15, E17, G18
D16, E18, G17
O
70
Terminal Description
