AM3359, AM3358, AM3357
AM3356, AM3354, AM3352
SPRS717F –OCTOBER 2011–REVISED APRIL 2013
www.ti.com
2.3.6.3 I2C
Table 2-53. I2C/I2C0 Signals Description
TYPE
[3]
SIGNAL NAME [1]
DESCRIPTION [2]
ZCE BALL [4]
ZCZ BALL [4]
I2C0_SCL
I2C0_SDA
I2C0 Clock
I2C0 Data
I/OD
I/OD
B19
C18
C16
C17
Table 2-54. I2C/I2C1 Signals Description
TYPE
[3]
SIGNAL NAME [1]
DESCRIPTION [2]
ZCE BALL [4]
ZCZ BALL [4]
I2C1_SCL
I2C1_SDA
I2C1 Clock
I2C1 Data
I/OD
A17, C19, F18,
K19
A16, D15, E17,
J15
I/OD
B17, D18, F19,
J18
B16, D16, E18,
H17
Table 2-55. I2C/I2C2 Signals Description
TYPE
[3]
SIGNAL NAME [1]
DESCRIPTION [2]
ZCE BALL [4]
ZCZ BALL [4]
I2C2_SCL
I2C2_SDA
I2C2 Clock
I2C2 Data
I/OD
I/OD
B18, D19, F17
A18, E17, E19
B17, D17, E16
A17, D18, E15
74
Terminal Description
